HB43K 43 meter XCMG truck concrete pump for sale in Philippines

  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines
  • HB43K 43 meter XCMG truck concrete pump for sale in Philippines

Share:
HB43K 43 meter XCMG truck concrete pump for sale in Philippines
FOB for Concrete Mach Reference Price:Get Latest Price
$100000.00-$200000.00 1 / EA (Min. Order)
Model: HB43K
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
HB43K 43 meter XCMG truck concrete pump for sale in Philippines
HB43K 43 meter XCMG truck concrete pump for sale in Philippines
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF
Summary
  • Dimension(L*W*H):11350*2500*3990mm
  • Weight:32500kg
  • Power(W):265000W
  • Model Number:HB43K
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Power Type:Diesel
  • Certification: ISO9001
Specifications
  • weight:32500.000kg
  • Condition:New
  • Moving Type:Wheel
  • Color:Color
  • Productivity: 170m3
  • Max. speed:85km/h
  • Engine output power:294/1800Km(r/min)
  • Feeding height:1510mm

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines.



XCMG 43 meter concrete pump HB43K is highly reliable and durable with seven technical highlights. More advanced boom structure technology ,More efficient rock valve pumping technology, Steadier stabilizer structure technology, Steadier reversing buffering technology, more reliable fully-hydraulic reversing technology, Ultra-low pressure loss hydraulic system technology, safer and smarter electrical control system.



XCMG 43 meter concrete pump HB43K has high power, high torque, high efficiency and energy saving and off-road ability. It is more flexible, long life characteristics.

* Large diameter (260 mm) Φ, large displacement (170 / hour) pumping systems.

* Material absorption can reach more than 85%.

* Effectively reduce emissions with the reversing, vulnerability of longer life.

* The pumping system adopts electric control reversing, reversing faster and the system impact smaller.

* The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.



HB43K 43 meter XCMG truck concrete pump for sale in Philippines

Description
Unit
Parameter value
Outline dimension
mm
11260×2500×3990
Overall weight
kg
31000
Model

ZZ5347V4847C1
Manufacturer

Sinotruk Group
Max. speed
km/h
90
Max. grade-ability
%
40
Wheelbase
mm
4600+1350
Tire

1200R20
Model

D12.42-30
Max. power
kW
278
Max. torque
N·m/(r/min)
1820/1100~1500
Displacement
L
10.837
Emission standard

Eruo III
Theoretical output
m³/h
170
Concrete pumping pressure
MPa
8
Theoretical pumping times
Time/min
23~26
Delivery cylinder diameter ×stroke
mm
φ260×2000
Max. diameter of pumping concrete
mm
40
Filling height
mm
1580
Concrete slump range
cm
8~23
Reach height
m
43
Reach depth
m
29
Slewingradius
m
37.3
Slewing angle
°
±270
Unfolding angle of the 1st section
°
90
Unfolding angle of the 2nd section
°
180
Unfolding angle of the 3rd section
°
180
Unfolding angle of the 4th section
°
230
Unfolding angle of the 5th section
°
210
Unfolding angle of the 6th section


Longitudinal span of stabilizer
mm
7700
Transverse span of front stabilizer
mm
7300
Transverse span of rear stabilizer
mm
7740

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines

HB43K 43 meter XCMG truck concrete pump for sale in Philippines
