XCMG original 25 ton truck crane QY25K price

  • XCMG original 25 ton truck crane QY25K price
  • XCMG original 25 ton truck crane QY25K price
  • XCMG original 25 ton truck crane QY25K price
  • XCMG original 25 ton truck crane QY25K price
  • XCMG original 25 ton truck crane QY25K price
  • XCMG original 25 ton truck crane QY25K price

Share:
XCMG original 25 ton truck crane QY25K price
FOB for Cranes Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: QY25K
Engine: SHANGCHAI
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG original 25 ton truck crane QY25K price
XCMG original 25 ton truck crane QY25K price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:QY25K
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:6m
  • Max. Lifting Height:42.15m
  • Max. Lifting Load:25ton
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:29400.000kg
  • Condition:New
  • Moving Type:Wheel
  • Engine rated power:206/2200kw/(r/min)
  • Engine rated torque:1112/1400N.m/(r/min)
  • Max. travel speed:75km/h

XCMG original 25 ton truck crane QY25K price

180 ton XCMG mobile all terrain truck crane XCA180.



XCMG truck crane QY25K is the product with high reliability inheriting XCMG classical and advanced technology about design and manufacture truck crane of many years and based on mature technology.



The operations of XCMG truck crane QY25K are very simple, convenient and flexible. It is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oilfield, industrial and mining enterprises, etc.



Advantages and highlights:



1. Bi-hexagonal cross-section boom has small depth-width ratio, strong bearing capacity, small deformation, strong anti bending and powerful lifting capacity.



2. Plug-in boom head effectively increases the boom connect length and reduces boom deformation.



3. It has superior travel and grade ability. The max. grade ability is 30%, max. travel speed is 75km/h.



4. Open fixed displacement pump and variable displacement motor system is adopted. High pressure variable displacement motor contributes to light load with high speed and heavy load with low speed.

XCMG original 25 ton truck crane QY25K price

Description
Unit
Parameter value
Overall length
mm
12650
Overall width
mm
2500
Overall Height
mm
3380
Wheel Base
mm
4425+1350
Track
mm
2074/1834/1834
Total vehicle mass in travel configuration
kg
29400
Axle load
Front axle
kg
6600
Rear axle
22800
Engine Model

SC8DK280Q3
Engine rated power
kw/(r/min)
206/2200
Engine rated torque
N.m/(r/min)
1112/1400
Max. travel speed
km/h
75
Min. travel speed
km/h
2.9
Min. turning diameter
m
22
Min. ground clearance
mm
260
Max. grade ability
%
30
Approach angle
°
16
Departure angle
°
13
Braking distance (at 30 km/h, full load )
m
≤10
Oil consumption per 100km
L
≤37
Exterior noise level during acceleration traveling
dB (A)
84
Noise level at seated position
dB (A)
90

XCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K priceXCMG original 25 ton truck crane QY25K price
