XCMG used Hydraulic Crawler Excavator XE700DA
XE700DA
Specs & Compare
Details
Select 3 models for comparison
Model Number
Brand Name
Place of Origin
Machine Weight
Maximum Digging Depth
Maximum Digging Height
Bucket capacity
Operating Weight
Max Digging Radius
Rated Speed
Certification
Used Equipment
XE700DA
XE700DA
XCMG
Jiangsu, China
69000 kg
6900 mm
11350 mm
4.6 m³
69000 kg
11580 mm
1800 rpm
--
+ Add a Product
+ Add a Product
Summary
- Model Number:XE700DA
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Machine Weight:69000 kg
- Maximum Digging Depth:6900 mm
- Maximum Digging Height:11350 mm
- Bucket capacity:4.6 m³
- Operating Weight:69000 kg
- Max Digging Radius:11580 mm
- Rated Speed:1800 rpm
Specifications
- weight:69000.000kg
- Condition:Used
- Moving Type:Other
- Area:Jiangsu Province
- Brand:XCMG
- Model:XE700DA
- Type:Crawler excavator
- Working_condition:other
- YEAR:Mar 2022
- Used_hours:99
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG used Hydraulic Crawler Excavator XE700DA
The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
The advanced structure and hinge points on the digging end and the industry’s largest rotating angle of the bucket ensure strong soil holding capacity.
Description | Unit | Parameter value | |||
Operating weight | kg | 69000 | |||
Bucket capacity | m³ | 2.4-4.6 | |||
Engine | Model | Engine | QSX15 | ||
Style | Direct injection | --- | √ | ||
Four strokes | --- | √ | |||
Water cooling | --- | √ | |||
Turbo-charging | --- | √ | |||
Air to air intercooler | --- | √ | |||
No. of cylinders | --- | 6 | |||
Output power | kW/ r/min | 336/1800 | |||
torque/speed | N.m | 2102/1400 | |||
Displacement | L | 15 | |||
Main performance | Travel speed(H/L) | km/h | 4.2/3.0 | ||
Gradeability | % | 35 | |||
Rotary speed | r/min | 7 | |||
Ground pressure | kPa | 101.4 | |||
Bucket digging force | kN | 363 | |||
Arm digging force | kN | 300 | |||
Travel traction force | kN | 450 | |||
Hydraulic system | Main pump | -- | 2 | ||
Rated flow of main pump | L/min | 2×450 | |||
Pressure of prime valve | MPa | 31.4/34.3 | |||
Pressure of travel system | MPa | 34.3 | |||
Pressure of swing system | MPa | 28.5 | |||
Pressure of pilot system | MPa | 3.9 | |||
Oil Capacity | Fuel tank capacity | L | 950 | ||
Hydraulic tank capacity | L | 500 | |||
Engine oil capacity | L | 48 | |||
Appearance size | Overall length | mm | 12130 | ||
Overall width | mm | 4410 | |||
Overall height | mm | 4700 | |||
Length of crawler | mm | 5955 | |||
Overall width of chassis | mm | 4000 | |||
Width of crawler | mm | 650 | |||
Wheel base of crawler | mm | 4685 | |||
Crawler gauge | mm | 2800/3350 | |||
Clearance under counterweight | mm | 1565 | |||
Min. ground clearance | mm | 853 | |||
Min. tail swing radius | mm | 4090 | |||
Max. digging height | mm | 11300 | |||
Working scope | Max. dumping height | mm | 7320 | ||
Max. digging depth | mm | 6950 | |||
Max. digging depth at the range of level 8 feet | mm | 6800 | |||
Max. vertical wall digging depth | mm | 5550 | |||
Max. digging reach | mm | 11580 | |||
Min. swing radius | mm | 4750 | |||
XCMG STORY
XCMG RECONDITIONED MACHINE
XCMG reconditioned machine is the second-hand machine program launched by XCMG for the
post market. XCMG takes advantage of its dealers network to collect the second-hand XCMG
machine that falls into strict standards: good condition, full function and low service hours. The
returned machine is then disassembled, repaired, painted, rebuilt and tested officially by XCMG,
and the product life is therefore extended. The price of XCMG reconditioned machine is far
lower than that of the new one, but its performance and safety are not compromised thanks to
XCMG's state-of-the-art processes and technologies. In order to dispel customers' concerns,
XCMG establishes a strict evaluation system for reconditioned machines and invites SGS to issue
third-party certification.
OUR TEAM
150+ SPECIALISTS
150+ specialists participate in the reconditioning process.
Inspection Team
Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine.
Reconditioning and Repairing Team
Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.
Issuing Report Team
Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.
OUR FACTORY
REMANUFACTURING FACTORY
RECONDITION PROCESSES
RECONDITION PROCESSES OF THE USED
We maintain a meticulous and rigorous attitude toward quality, focusing on extraordinary creativity,
elaborate designs and exquisite craftsmanship.
COLLECTION
Examine the working conditions, conduct static and dynamic assessment on the used machine. Only machines with
light deprecation, low working hours and full functions can be collected.
INSPECTION
Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the
machine. More than 300 details are checked and compared to XCMG standard. Recondition plan is then decided.
RECONDITIONING AND REPAIRING
Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.
TESTING
Follow the test procedure, ensure the performance and durability of the machine. Unqualified products are returned to step 3.
READY FOR DELIVERY
Ready for Delivery!!!
ISSUING REPORT
Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.
PAINTING
The whole machine is repainted to restore its appearance. Bright as new.
FAQ
FREQUENTLY ASKED QUESTIONS
1.What’s the warranty policy for XCMG reconditioned machines?
The warranty policy does not cover the covering parts and wearing parts. For engine, gearbox, hydraulic pump,
distriutor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first.
If there is any problem within warranty period, XCMG will provide solutions accordingly.
2.How about the quality of your machine?
The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines
will be guaranteed. They are ready to work for you and XCMG will provide test report from professtional institute.
3.Are you the original manufacturer?
Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of constrcution machineries.
4.Can you satisfy my special requirement?
As the manufacturer,XCMG will review the special requirement and recondition it as per request (if possible).
5.What is accpetable payment terms?
Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight.
If any other questions, please feel free to contact with us.
If any other questions, please feel free to contact with us.
