XZJJ SC270/270 double cage new type crane elevator

$50000.00-$80000.00 1 / Set (Min. Order)
Model: SC270/270
Engine: Juli
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XZJJ SC270/270 double cage new type crane elevator

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Loder Weight:2700kg*2
  • Dimension(L*W*H):3200*1500*2500
  • Max Lifting Height:450m
  • Hoisting Speed:0-40m/min
  • Rated Loading Capacity(kg):2700kg*2
  • Model Number:SC270/270
  • Brand Name:XZJJ
  • Place of Origin:Xuzhou Jiangsu China
  • Certification:ISO9001,CE

Specifications

  • Weight:15000.000kg
  • Condition:New
  • Moving Type:Other
  • high rise conveyor:geared elevator
  • outdoor conveyor:two cages

The SC270/270 construction hoist the new-generation product designed with advanced technology from domestic and abroad introduced to our company .Compared with traditional construction hoist,the new generation SC200/200 is more comfortable ,safe reliable and convenient for dismantling and maintenance with more reasonable and compact structure ,strong and double cage,attractive appearance and delicate parts.

There are many types of drive mechanisms include three-motors ,two motors and energy saving new type etc.The transmission plate is fitted at top of cage to avoid any header accident and provide a comfortable cage for passengers.Floor calling system,over load limiter,volt displayer are integrated on control panel for convenient operation.Many patent technologies such as anti-derail technology are used on each guide wheels to ensure safe running.

XZJJ SC270/270 double cage new type crane elevator

Cage

Consists of steel structure,firm wire mesh wall,entrance and exit gates.Guide rollers guide the cage to travel along the mast.

Safety hook on the cage main frame prevents the cage climbing off the top.

The cage roof with safety railing servers as working platform during erection.One can easily get up on the roof for erection and maintenance because of a trap door in the roof and a ladder in the cage.

XZJJ SC270/270 double cage new type crane elevator

Tie-in

There are several types of tie-in.Select one of them according to need.Tie-in are available in variable in variable sizes.

Distance between the tie-ins is about 6~9m along the mast.

XZJJ SC270/270 double cage new type crane elevator

Items

Unit

Parameter

SC270/270

SC270/270BP

SC270/270Z

SC270/270G

Rated load

kg

2*2700

Maximum lifting heigh

m

250

450

Rated lifting speed

M/min

33

0-40

0-63

0-96

Jid attachment rated load

kg

350

Motor power

kw

2*3*15

2*3*18.5

2*3*18.5

2*2*22

Rated current

A

2*3*23.2

2*3*37.8

2*3*39

Inverter power

kw

/

37

75



Security Anti-dropping

/

SAJ4.0-1.2

SAJ6.0-1.2

SAJ6.0-1.4

SAJ6.0-2.0

Voltag of power supply

V/Hz

380/50

380/50

380/50

380/50

Power capacity

KVA

120

120

120

120

The size of the standard section

mm

800*800*1508

800*800*1508

800*800*1508

800*800*1508

The hoist space(L*W*H)

mm

3200*1500*2500

3200*1500*2500

3200*1500*2500

3200*1500*2500
