HAITUI HD22 hydraulic bulldozer 220HP with high efficient price

  • HAITUI HD22 hydraulic bulldozer 220HP with high efficient price
  • HAITUI HD22 hydraulic bulldozer 220HP with high efficient price
  • HAITUI HD22 hydraulic bulldozer 220HP with high efficient price

Share:

HAITUI HD22 hydraulic bulldozer 220HP with high efficient price

$50000.00-$100000.00 1 / EA (Min. Order)
Model: HD22
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
HAITUI HD22 hydraulic bulldozer 220HP with high efficient price

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Dimension(Long * Breadth * High):5460×3725×3395
  • Machine Weight:23500 kg
  • Model Number:HD22
  • Brand Name:HAITUI
  • Place of Origin:Jining,Shandong
  • Certification:ISO9001

Specifications

  • Weight:23500.000kg
  • Condition:New
  • Moving Type:Crawler
  • Dozing capacity:6.4 m³
  • Max tractor force:202 KN
  • Max pressure:14 MPa
  • Blade width:3725 mm
  • Blade height:1317 mm

HAITUI HD22 hydraulic bulldozer 220HP with high efficient price



HAITUI HD22 hydraulic bulldozer 220HP with high efficient.



HAITUI HD22 hydraulic bulldozer 220HP with high efficient adopts advanced technologies such as centralized lubrication, centralized pressure measurement and automatic tightening of crawlers. It can be equipped with a variety of working devices and cabs to meet the various working conditions. They are ideal and efficient equipment for earth and stone construction work and bulk scraping.



Advantages:



1.The highly reliable power shift transmission, stable torque converter and the two-stage straight-tooth structure final drive transmit power efficiently.



2.It can realize automatic fault diagnosis and full monitoring.The overall cast instrument panel integrates air conditioning, electrical appliances and instruments into one, which is more beautiful and luxury.



3.The main frame of the full box structure adopts steel plate welded full box type integral structure, which is welded with the rear axle box. It has high impact load bearing capacity and resistance to bending and twisting. High quality weld seam ensures the main frame has a full life cycle.



4.According to the ergonomic design, the driver's seat and armrest can be adjusted up and down, the shifting, steering and throttle are placed on the left side, and the soft shaft structure is adopted. The working device is operated on the right side, and the servo control system is used to make the operation process more light and flexible.

HAITUI HD22 hydraulic bulldozer 220HP with high efficient price

Model

Unit

HD22

 Type



220HP Standard Hydraulic Crawler Type

Engine model



CUMMINS NT855-C280S10

Displacement

L

14.01

Rated power

kw/rpm

175/1800

Max.torque

N.m/rpm

1030/1250

 Operating weight

T

23.5

Dimension(no ripper)

mm

5460×3725×3395

Grounding length

mm

2730

Ground pressure

Mpa

0.077

 Track gauge

mm

2000

 Dozing capacity

6.4

 Blade width

mm

3725

 Blade height

mm

1317

 Max drop below ground

mm

540

 Track shoe width

mm

560

 Pitch

mm

216

Quantity of track link



38

 Quantity of Carrier rollers



4

 Quantity of Track rollers



6

 Max pressure

MPa

14

Discharge

L/min

262

 Max tractor force

KN

202

 Forward Speed

Km/h

F1:0-3.6

F2:0-6.5

F3:0-11.2

  Rear Speed

Km/h

R1:0-4.3

R2:0-7.7

R3:0-13.2
