XCMG official 2m XM200E China mini road cold planer milling machine

$100000.00-$10000000.00 1 / EA (Min. Order)
Model: XM200E
Engine: WEICHAI
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG official 2m XM200E China mini road cold planer milling machine

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Dimension(L*W*H):6750*2500*2900mm
  • Weight:28500kg
  • Power(W):353kW
  • Model Number:XM200E
  • Brand Name:XCMG
  • Place of Origin:Xuzhou, Jiangsu, China
  • Milling width (mm):2m
  • Milling depth (mm):300mm
  • Certification:CE/ISO9001

Specifications

  • Weight:28500.000kg
  • Condition:New
  • Moving Type:Other
  • Fuel tank:800L
  • Operating speed:0~34m/min
  • Gradeability:80%
  • Travel speed:0~4.5km/h

XCMG official 2m XM200E China mini road cold planer milling machine

XCMG official 2m XM200E China mini road cold planer milling machine.



XCMG XM200E road cold planer milling machine is the maintenance construction machinery of asphalt concrete pavement, mainly used for excavation and renovation of highway, urban road, airport, freight yard, parking lot and other large area of asphalt concrete pavement.



The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.



Performance and characteristic:



1.Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.



2.Compact three-wheeled machine with front-wheel drive.



3.The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.



4.The imported hydraulic elements have high working reliability.



5.Hydraulic handheld breakers and rumble strip equipment can be selected.

XCMG official 2m XM200E China mini road cold planer milling machine

Model

 Unit

XM200E



Max. milling with

mm

2000



Max. milling depth

mm

300

Milling wheel

Number of tools



162

Drum diameter with tools

mm

980

Engine

Model



DHP12

Rated power

kW

353

Rated speed

rpm

2100

Specifications

Operating speed

m/min

0~34

Travel speed

km/h

0~5

Ground clearance

%

80

Ground clearance

mm

≤320

Operating weight

kg

28500

Volume

Fuel tank

L

800

Hydraulic oil tank

L

300

Water tank

L

2300

Conveyor

Width

mm

800

Measurement

Overall machinery LxWxH

mm

6750×2500×2900

Conveyor LxWxH

mm

8000×1150×900

Travel mode



Track

XCMG official 2m XM200E China mini road cold planer milling machineXCMG official 2m XM200E China mini road cold planer milling machineXCMG official 2m XM200E China mini road cold planer milling machineXCMG official 2m XM200E China mini road cold planer milling machineXCMG official 2m XM200E China mini road cold planer milling machineXCMG official 2m XM200E China mini road cold planer milling machine
