XCMG 55 ton lifting construction machinery crawler crane XGC55 price

  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price
  • XCMG 55 ton lifting construction machinery crawler crane XGC55 price

Share:
XCMG 55 ton lifting construction machinery crawler crane XGC55 price
FOB for Cranes Reference Price:Get Latest Price
$100000.00-$1000000.00 1 / EA (Min. Order)
Model: XGC55
Engine: SHANGCHAI
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 55 ton lifting construction machinery crawler crane XGC55 price
XCMG 55 ton lifting construction machinery crawler crane XGC55 price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • Product PDF
Summary
  • Model Number:XGC55
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Max. Lifting Height:52m
  • Rated Lifting Moment:203.5t.m
  • Rated Loading Capacity:55 ton
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:463000.000kg
  • Condition:New
  • Moving Type:Crawler
  • Max. travel speed:1.37/1.22km/h
  • Max. slewing speed:2.45/2.2r/min
  • Grade ability:30%
  • Rated Power:155/153kW

XCMG 55 ton lifting construction machinery crawler crane XGC55 price

XCMG 55 ton lifting construction machinery crawler crane XGC55.



XCMG crawler crane XGC55 is designed and developed independently in absorption of foreign advanced technology and combined with China domestic work conditions.



Performance Characteristics:



1. Optimized hydraulic system design

* Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance.



* XCMG crawler crane XGC55 use of highly integrated LUDV main valve, to ensure operation efficiency.



* Optional unique independent bypass filtration in the industry,  and anti-emulsifying ability.



2. Main/ auxiliary hook one-key-switch-over function

One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.



3. Universal and modular design

Common platform products with fixed jib, single top, both-sided counterweight, luffing mechanism, hydraulic pump and main valve block can achieve universal and interchangeable use, greatly reduce purchase, transport and maintenance costs.

XCMG 55 ton lifting construction machinery crawler crane XGC55 price

Items
Unit
Parameter value
Max. rated lifting load of main boom
(t)
55
Max. rated lifting load of fixed jib
(t)
11.4
Max. lifting load moment
(t.m)
203.5
Max. rated lifting load of boom single pulley
(t)
6
Main boom length
(m)
13~52
Main boom luffing angle
(°)
-3~80
Fixed jib length
(m)
7~16
Max. size of single unit for transport (L×W×H)
(m)
12.04×3.45×3.36
Installation angle of fixed jib
(°)
10,30
Max. single line speed of hoist system
(m/min)
125
Max. single line speed of main luffing system
(m/min)
87/78
Max. slewing speed
(r/min)
2.45/2.2
Max. travel speed
(km/h)
1.37/1.22
Gradeability
(%)
30
Average ground pressure
(MPa)
0.06
Model
-
SC7H210.1G3/QSB6.7
Engine power
(kW)
155/153
Emission
-
National III stage/Europe III
Crane overall mass
(t)
46.3(Main hook,13m boom)
Max. weight of single unit for transport
(t)
28.6
