XCMG Electric Forklift 4.5 Ton Lifter Machine Electric Truck FB45-AZ1 Price
Summary
- Fork Width:150mm
- Fork Length:1070mm
- Min Lifting Height: 2250mm
- Max Lifting Height:4260mm
- Rated Loading Capacity:4500Kg
- Power Source:AC Motor
- Model Number:FB45-AZ1
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- Weight:4500.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Electric Forklift 4.5 Ton Lifter Machine
Electric Truck FB45-45AZ1.
XCMG Electric Forklift
FB45-AZ1 combining the Italian ZAPI electric controller, ZAPI-SUPEREC AC
motors, and HAKWER battery, as well as the excellent hydraulic system, these
features guarantee your material handling become the most cost-efficient.
Performance Characteristics:
1.Full AC System
2.OPS System
3.Comfortable
Operator Space, optimized steering wheel, operating handle and pedals.
4. Side-way Battery
Change System
5. Lower Energy
Consumption and Energy Regeneration Function
6.Easy-to-read operator
display
7.World Class Gear
Box System
8. Automatic
Maintenance Alarm
|
Model |
FB45-AZ1 |
|
|
Rated Load Capacity |
Q(kg) |
4500 |
|
Load Centre |
C(mm) |
500 |
|
Lift Height |
H3(mm) |
3000 |
|
Free Lift |
H2(mm) |
84 |
|
Fork Size (L×W×T) |
L/W/T(mm) |
1070×150×50 |
|
Length (To Fork Face) |
L1(mm) |
2940 |
|
Width |
B1(mm) |
1612 |
|
Mast Lowered Height |
H1(mm) |
2250 |
|
Mast Extended Height (With Backrest) |
H4(mm) |
4260 |
|
Overhead Guard Height |
H5(mm) |
2300 |
|
Turning Radius |
Wa(mm) |
2705 |
|
Fork Overhang (Wheel Center to Fork Face) |
X(mm) |
550 |
|
Front Tread |
B2(mm) |
1300 |
|
Rear Tread |
B3(mm) |
1200 |
|
Ground Clearance |
H6(mm) |
125 |
|
Wheelbase |
Y(mm) |
2000 |
|
Fork Spread (Min/Max) |
mm |
250/1380 |
|
Travel Speed (Full Load) |
km/h |
12.5 |
|
Travel Speed (No Load) |
km/h |
13.5 |
|
Lifting Speed (Full Load) |
mm/s |
290 |
|
Lifting Speed (No Load) |
mm/s |
400 |
|
Total Weight (Include Battery Box) |
Kg |
7020 |
|
Diver Motor |
Kw |
11×2 |
|
Pump Motor |
Kw |
25.4 |
|
Battery (Standard) |
V/Ah |
80/840 |
|
Controller Type |
AC |
|
|
Operating Pressure |
Mpa |
20 |
|
Controller Manufacturer |
ZAPI |
