XCMG official 7 ton China front wheel loader LW700KN
Summary
- Rated Load:7000kg
- Dimension(Long* Breadth * High):9455*3430*3630 mm
- Type:wheel loader
- Place of Origin:Jiangsu, China
- Model Number:LW700KN
- Brand Name:XCMG
- Certification:CE/ISO90001
Specifications
- Weight:28500.000kg
- Moving Type:Other
- Engine Brand:WEICHAI
- Rated Load:other
- Bucket Capacity:0.5 - 2m³
- Bucket capacity:6m3
- Machine Weight:25500kg
- Wheel base:3450mm
- Power:226KW
- Max.breakout force:150KN
- Max.horse power:220KN
- Reach at maximum lift:1388mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG official 7 ton China front wheel loader LW700KN.
LW700KN is XCMG's latest generation 7t loader product applied with XCMG’s exclusive globalized platform technology, with the comprehensive leadership in the fields of energy-conservation, efficiency, reliability, comfort, and maintainability.
The corresponding models are designed respectively for the hard heavy materials (such as ores) and light bulk materials (such as coal) to realize the best productivity and are extensively applicable for the production organizations in ports, mines, and logistics enterprises.
Model Characteristics:
* Higher safety, broader visual field, and more comfortable operations.
* Achieve higher efficiency and reliability.
* Reduce the impact on drive shaft and improve the drive reliability.
|
Description |
Unit |
Parameter value |
|
|
Wheel base |
mm |
3450 |
|
|
Tread |
mm |
2360 |
|
|
Dump clearance at maximum lift |
mm |
3515 |
|
|
Reach at maximum lift |
mm |
1388 |
|
|
Height of hinge at maximum lift height |
mm |
4780 |
|
|
Working height (fully lifted) |
mm |
6560 |
|
|
Overall machine dimension L×W×H |
mm |
9455×3430×3630 |
|
|
Rated operating load |
kg |
7000 |
|
|
Bucket capacity |
m³ |
6 |
|
|
Machine weight |
kg |
25500 |
|
|
Max.breakout force |
kN |
150 |
|
|
Max.horse power |
kN |
220 |
|
|
Lifting time of boom |
s |
≤6.5 |
|
|
Total cycle time |
s |
≤11 |
|
|
Minimum turning radius (at tire center) |
mm |
5920 |
|
|
Articulation angle |
° |
±40 |
|
|
Gradeability |
° |
28 |
|
|
Tyre size |
26.5R25 |
||
|
EngineModel |
WD12G310E221 |
||
|
Rated Power/Speed |
kW/rpm |
226/2100 |
|
|
Travel Speed |
I-gear(F/R) |
km/h |
7/7 |
|
II-gear(F/R) |
km/h |
12.7/12.7 |
|
|
III-gear(F/R) |
km/h |
27/27 |
|
|
Ⅳ-gear(F) |
km/h |
38 |
|
