XCMG 100HP GR1003 small road grader for sale

  • XCMG 100HP GR1003 small road grader for sale
  • XCMG 100HP GR1003 small road grader for sale
  • XCMG 100HP GR1003 small road grader for sale
  • XCMG 100HP GR1003 small road grader for sale
  • XCMG 100HP GR1003 small road grader for sale
  • XCMG 100HP GR1003 small road grader for sale

Share:
XCMG 100HP GR1003 small road grader for sale
FOB for Road Mach Reference Price:Get Latest Price
$40000.00-$50000.00 1 / EA (Min. Order)
Model: GR1003
Engine: WEICHAI
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 100HP GR1003 small road grader for sale
XCMG 100HP GR1003 small road grader for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:7500.000kg
  • Condition:New
  • Moving Type:Other
  • Dimension(L*W*H):7130* 2375*3150mm
  • Rated power/speed:75/2200kW/rpm
  • Total weight:7500kg
  • Tractive effort f=0.75:39kN
  • Maximum gradeadbility:25%

XCMG 100HP GR1003 small road grader for sale

XCMG 100HP GR1003 small road grader.



XCMG GR1003 road grader is mainly used for ground leveling, ditching, slope scraping,bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc.



XCMG road grader GR1003 is the necessary construction machinery for national defense construction,mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.



Performance Characteristics:



1. Efficient operation: the optimized blade shape can turn and remove the soil quickly and efficiently, and realize optimal load distribution and the minimum material accumulation within the rotary discarea.



2. Safe and reliable: full hydraulic braking system, load sensing steering system, international supporting key components, ensuring safe and reliable system.



3. Advanced processing technology: all important parts and components are welded by international advanced welding equipment, which is characterized by high weld strength, uniform welding line and high welding quality.



4. Maintenance accessibility: XCMG road grader GR1003 adopting the backflip hydraulic lift hood, the machine cover is has large opening, easy for maintenance and repair of the machine.XCMG 100HP GR1003 small road grader for sale

Item

Unit
GR1003
Basic parameters
Engine model

WP4.1
Rated power/speed
kW/rpm
75/2200
Overall dimension(standard)
mm
7130 x 2375 x 3150
Total weight(standard)
kg
7500
Tire specification

16/70-24/13.00-24
Ground clearance
mm
550
Tread
mm
1900
Space of front and rear axles
mm
5135
Space of middle and rear wheels
mm
/
Performance parameters
Forward velocity
km/h
5、8、11、17、24、38
Reverse speed
km/h
5、11、24
Tractive effort f=0.75
kN
≥39
Maximum gradeadbility
%
≥25
Inflation pressure of tires
kPa
300
Working system pressure
MPa
16
Transmission pressure
MPa
1.3-1.8
Working parameters
Maximum steering angle of front wheels
°
±49
Maximum inclination angle of front wheels
°
±17
Maximum swing angle of front axle
°
±15
Maximum swing angle of balance box
°
±16
Maximum steering angle of frame
°
±27
Maximum turning radius
m
6
Blade
Maximum lifting height
mm
310
Maximum shoveling depth
mm
350
Maximum lateral inclination angle
°
45
Cutting angle
°
28-70
Oil filling amount
Slewing angle
°
120
Length x chord height
mm
3048 x 450
Coolant
L
50
Fuel tank
L
260
Engine
L
18
Transmission
L
26
Balance box
L
/
Drive axle
L
28
Hydraulic oil
L
89

XCMG 100HP GR1003 small road grader for saleXCMG 100HP GR1003 small road grader for saleXCMG 100HP GR1003 small road grader for saleXCMG 100HP GR1003 small road grader for saleXCMG 100HP GR1003 small road grader for saleXCMG 100HP GR1003 small road grader for sale
