XCMG 30 ton XCR30 hydraulic rough terrain crane price

$100000.00-$500000.00 1 / EA (Min. Order)
Model: XCR30
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG 30 ton XCR30 hydraulic rough terrain crane price

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Model Number:XCR30
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:6.8m
  • Max. Lifting Height:42.2m
  • Rated Lifting Moment:989.8 kN.m
  • Rated Loading Capacity:30 Ton
  • Application:Construction
  • Certification:CE/ISO9001

Specifications

  • Weight:27334.000kg
  • Condition:New
  • Moving Type:Other
  • Min Turning Radius:9.6m
  • Max Travel Speed:41km/h
  • Min.ground clearance:345mm
  • Engine Rated Power:145kw/(r/min)
  • Max Gradeability:78%

XCMG 30 ton XCR30 hydraulic rough terrain crane price

XCMG 30 ton XCR30 hydraulic rough terrain crane.



XCMG rough terrain crane XCR30 the total rated loads given in the rated load charts are the maximum lifting capacity when the crane is set up on firm and level ground.



1. The working radius shown in the rated load charts is the radius when the load is lifted off the ground, and it is the actual value including loaded boom deflection.



2. Before beginning lifting operation, the operator should know the weight of the load to be lifted and its working range, and then select proper working conditions.



3. Observe the boom angle limit. Never operate the crane with the boom angle beyond the recommended limit even if a load is not being carried. Otherwise, the crane will tip.



4. The boom should be extended according to the telescoping code shown by digits, which means the percentage of boom sections extended.

XCMG 30 ton XCR30 hydraulic rough terrain crane price

Project
Unit
Parameter
Measurements Parameters


Wheel Base
(mm)
3600
Wheel Track
(mm)
(Front/Rear)2300/2300
Weight Parameters


Gross Vehicle Weight When Driving
(kg)
27334
Axle Load
(kg)
(1st axle/2nd axle)13157/13763
Kinetic Paremeter


Engine Type
-
B6.7
Engine Net Power
(kw/r/min)
145
Driving Parameters


Max Travel Speed
(km/h)
41
Min Travel Speed
(km/h)
1.6
Swerve


Min Turning Radius
(m)
9.6
Max Gradeability
(%)
78
Min. Ground Clearance of Machine
(mm)
345
Approach Angle
(°)
20.5
Departure Angle
(°)
19.6
Braking Distance
(m)
9
Major Performance Parameters


Max. Rated Lifting Capacity
(t)
30
Min. Rated Range
(m)
3
Max. Load Moment of Basic Jib
(kN·m)
989.8
Radius of Gyration of Turntable Tail
(mm)
3823
Outrigger


Longitudinal
(m)
6.8
Horizontal
(m)
6.8
Max. Lifting Height


Basic Boom
(m)
10.2
Longest Main Boom
(m)
34.4
Longest Main Boom + Auxiliary Boom
(m)
42.2
Boom Length of Crane


Basic Boom
(m)
10.8
Longest Main Boom
(m)
35
Longest Main Boom + Auxiliary Boom + Extension
-
-
Working Speed


Max. Slewing Speed
(r/min)
2.5
Lifting Speed


Main Hoisting Mechanism
(m/min)
140
Auxiliary Hoisting Mechanism
(m/min)
140
