XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift

  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
  • XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift

Share:
XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
FOB for Loader Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: HNT50-2
Engine: Cummins
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Max Lifting Height:7.3m
  • Rated Loading Capacity:5ton
  • Power Source:Diesel
  • Model Number:HNT50-2
  • Brand Name:XCMG
  • Place of Origin:Xuzhou, Jiangsu, China
  • Certification:CE/ISO9001
Details
  • weight:13000.000kg
  • Condition:New
  • Moving Type:Other
  • Operating weight:13000kg
  • Wheel base:2988mm
  • Rated power / Rated turning speed:75/2200kW/rpm
  • Max. Travelling speed:25km/h
  • Grade ability:20%
  • Engine:Dongfeng Cummins

XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift.



The telescopic forklift is a new type of loading and unloading machine, which was equipped with fork and side shifter. The machine is suitable for the lifting and stacking of cargoes, and can also be used in installation and maintenance of road lighting equipment’s and installation of various underground pipes (such as water pipes, gas pipes, etc.).



And can be widely applied to factories, stations, docks, freight yard, post and telecommunications, forest, building materials, warehouses and other places. It is a wide adaptability and high efficiency loading and unloading machine.



Performance Characteristics:



1.Using well-known brand diesel engine, strong-power, energy saving and environment protection, to meet the requirements of efficient operations.



2.Double turbo hydraulic torque converter, stepless speed change. Single-lever control transmission system, with 2 speeds for forward and reverse gears, easier to operate.



3.Use dual-pump combined hydraulic system, greatly reduce the fuel 2 consumption and energy consumption.



4.With full hydraulic coaxial flow amplification steering system, turning radius for rear steering axle is small, steering light and flexible.



5.Using the integral frame, can provide good rigidity and strength, to ensure high reliability of this type of chassis.

XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift

Items

Unit

HNT50-2

Basic parameter

Rated load

kg

5000

Load center

mm

500

Load capacity @ max. Forward reach

kg

1500

Basic boom max. Lifting height

mm

4500

Max. Lifting height

mm

7300

Max. Horizontal reach

mm

5700

Min. Horizontal reach

mm

1500

Min. Ground clearance

mm

310

Min. Turning radius

mm

6800

Angle

Boom frame upward angle

°

43

Boom frame downward angle

°

14

Operating weight

kg

13000

Overall dimension

Length (with fork)

mm

Width

mm

2300

Height

mm

2715

Wheel tread

mm

1635/1785

Wheel base

mm

2988

Rated power / Rated turning speed

kW/rpm

75/2200

Driving system

Max. Travelling speed (unloaded)

km/h

25

Grade ability

%

≥20%

Tyre

Front(2 pcs)

-

11.00-20

rear(2 pcs)

-

9.00-20

Engine

Dongfeng Cummins

-

4BTA3.9-C100II

-

QSB3.9-C100

XCMG 7m telehandler HNT50-2 China new 5 ton telescopic forkliftXCMG 7m telehandler HNT50-2 China new 5 ton telescopic forkliftXCMG 7m telehandler HNT50-2 China new 5 ton telescopic forkliftXCMG 7m telehandler HNT50-2 China new 5 ton telescopic forkliftXCMG 7m telehandler HNT50-2 China new 5 ton telescopic forkliftXCMG 7m telehandler HNT50-2 China new 5 ton telescopic forklift
