HY-200 self loading concrete mixer

Chat Now 1 / EA (Min. Order)

Model： HY-200

Engine： Yunnei 76kw engine

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Product:

HY-200 self loading concrete mixer

Quantity:

- + /EA

Content:

*Email:

Full Name:

Mobile phone:

Summary
Specifications

Summary

Dimension(L*W*H):6380*2470*2820mm(3630mm)
Weight:5800kg
Brand Name:HONGYUAN

Specifications

Weight:5600.000kg
Condition:New
Moving Type:Other
Min turning radius :3.3m/r
Cooling type:Water Cooling

Model	Desc	Qty	EXW price
HY200 mobile self loading concrete mixer with 240°rotation function	Yunnei 76kw engine . Concrete output productivity 2.0 cbm Automatic weighting system with printer double reverse camera . Air conditioner 4 batches per hour. Hydraulic Torque Converter Transmission, 4 wheel drive ,articulated style. 20.5/70-16 front tyres16/70-20 rear tyres . Turbo-Wom rotation . automatic upper water system ,with pump and pipes. warning light, back sound, radio, fan, hand brake, extinguisher, window hammer, Easy damaged spare parts ,tool box.	1
	240°rotation function
Total

Name	Item		Spec
Overall machine	Net weight		5800kg
	Overall size		638024702820mm(3630mm)
	Transmission		Full Hydraulic
			4WD
	Brake		Air brake
	Chassis		Off-road
	Wheelbase		2600mm
	Loader bucket		Capacity	0.3cbm
			Control	Hydraulic
	Tilt Angle		30%
	Speed		High speed	0-25KM/H
			Low speed	0-9KM/H
		Min turning radius	3.3m/r
		Tyre Model	16/70-20 front 20.5/70-16 rear
Engine		Type	Yunnei
		Rated Power/RPM	76KW/2400RPM
		Max Torque/RPM	460N.W/1400RPM
		Cylinder	4
		Starter	Electric
		Cooling type	Water Cooling
Maxing Drum		Drum full capacity	3.0cbm
		Drum work capacity	2.0cbm
		Bank angle	16°
		Self rotation angle	240°
		Rotation speed	21R/min
Chute		Swing Angle	≥60°
		Angle control	Hydraulic
		Size	110CM
Loader		Weight model	Computer control
			Concrete standard	C15.C20.C25.C30
		Accuracy	Cement	≤±2%/time
			Relative error	≤±3%/time
			Water	≤±1%/time
			Additive	≤±1%/time
			Admixture	≤±2%/time
Loader control		Hydraulic control 4 way stick
