XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
  • XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

Share:
XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
FOB for Concrete Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: G10K
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
  • 360-Degree VR Videos
Summary
  • Dimension(L*W*H):9510x2500x3970mm
  • Weight:14600kg
  • Model Number:G10K
  • Brand Name:XCMG
  • Place of Origin:China
  • Power Type:Diesel
  • Type:Concrete Truck Mixer
  • Certification:CE/ISO9001
Details
  • weight:14600.000kg
  • Condition:New
  • Moving Type:Wheel
  • Geometric volume:16.8m³
  • Max. diameter of drum:2280mm
  • Drum length:5596mm
  • Mounting tilt angle:13.5°
  • Rotary speed:0~14r/min
  • Charging speed:≥3m³/min
  • Discharging speed:≥2m³/min
  • Residual ratio of discharging:<0.7%
  • Range of slump:5~21cm
  • Volume of water tank:450L

XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

Sinotruk Howo Hot Sale 10m3 Concrete Mixer Truck G10K.



1,On the basis of in-depth and integrative research on the industry, the XCMG new generation truck mixers are system optimized by taking the integrated modularization design to truly realize the integrated innovation.

2,Particular mixing technology with continuous trace, original double log spiral technology with changeable lift angle and changeable screw pitch and optimized auxiliary blades and pressure-reducing hole design can make the operation path of the spiral in perfect state and can ensure the best concrete flowing trend in mixing drum and more uniformly discharging.

3,Twin-output control, lightweight technology and anti-scattering technology make the vehicle more environmental and more effective.

4,Optimized chassis matches with upper parts and such parts as front base and accessory beam, rear base and tilted beam, rear base and accessory beam adopt integration design. After force bearing research and analysis and long-term application, the best position of the connecting point between tilted beam and rear base are confirmed and thus deformation and break of cross beam can be avoided effectively.

5,Internationally branded hydraulic transmission system: Hydraulic pump, motor and speed reducer of such world-famous brands as ZF, Rexroth, Bonfiglioli, PMP, TOP are adopted to make the power more sufficient, system more steady and reliable and service life longer.

XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

Description

Unit

Parameter value

Performance of mixing drum

Geometric volume

16.8

Max. diameter of drum

mm

2280

Drum length

mm

5596

Mounting tilt angle

°

13.5

Rotary speed

r/min

0~14

Charging speed

m³/min

≥3

Discharging speed

m³/min

≥2

Residual ratio of discharging

%

<0.7

Range of slump

5~21

Hydraulic system

Oil pump


World-famous brand

Motor


World-famous brand

Speed reducer


World-famous brand

Hydraulic circuit


Closed type

Water supply

Volume of water tank

L

450

Way of water supply


Air pressure

Overall machine

Chassis brand


XCMG

Chassis model


NXG3250D5NCX

Steering wheel


Left steering wheel

Curb mass

14600

Driving type


6×4

Wheelbase

mm

3800+1350

PTO way


Flywheel PTO

Outline dimension

(L×W×H)mm

9510×2500×3970

Engine

Model


WP10.350E53

Rated power

Kw/r/min

257

Displacement

L

9.726

Emission standard


Euro V

XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale


uMore  concrete truck mixer


XCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for SaleXCMG Official 10m3 Mobile Concrete Mixer Machine Truck G10K for Sale

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
