XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining
  • XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

Share:

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

Chat Now 1 / EA (Min. Order)
Model: LW1200KN
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications
  • 360-Degree VR Videos

Summary

Specifications

  • Weight:50000.000kg
  • Rated Load:12000kg
  • Dimension:12337*3875*4319mm
  • Type:Mining Loader
  • Place of Origin:Jiangsu, China
  • Model Number:LW1200KN
  • Brand Name:XCMG
  • Certification:CE/ISO90001

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader.



Mine wheel loader LW1200KN is the most popular model of China 12t huge wheel loader, Now LW1100KN is upgrading to new model LW1200KN equipped with EURO III engine with electric injector, new model will have high performance.



Performance Characteristics:



1.The XCMG’s latest integral FOPS&ROPS cab is globally developed and designed to incorporate the world’s most advanced technologies and reach the world’s leading level.



2.The integral cab structure is connected with the frame by silicone oil shock absorbers and is equipped with air cushioned seats, featuring large space, broad visual field, good sealing performance, low noise, and high safety and comfort.



3.The scientifically matched and in-depth optimized drive system assembly and the world’s leading quality drive parts ensure the high stability and reliability of the drive system and realize the maximum utilization of engine power.



4.The load-sensing variable technology is adopted to supply pressure and flow depending on the working needs, which improves the fuel utilization efficiency by 15%.

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

Description

Specification

Unit

Rated operating load

12000

kg

Bucket capacity

6.5

Machine weight

50000

Kg

Wheel Tread

2710

mm

Max.breakout force

394

kN

Total hydraulic cycle time

15.3

s

Min.turning radius over tyres

7622

mm

Articulation angle

40

°

Gradeability

25

°

Tyre size

radial35/65R33



Overall machine dimension L*M*H

12337*3875*4319

mm

Model

Cummnis



Rated Power/Speed

418/2000

kW/rpm

Travel Speed (I-gear F/R)

6.5/6.5

km/h

Travel Speed (II-gear F/R)

12/12

km/h

Travel Speed (III-gear F/R)

20/20

km/h

Travel Speed(IV-gear F/R)

33/33

km/h

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For MiningXCMG Official LW1200KN 12 ton Large Mine Wheel Loader For MiningXCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining





uMore Mine Wheel Loader



XCMG Official LW1200KN 12 ton Large Mine Wheel Loader For MiningXCMG Official LW1200KN 12 ton Large Mine Wheel Loader For MiningXCMG Official LW1200KN 12 ton Large Mine Wheel Loader For Mining

Send your message to this supplier:

Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
