ROADWAY Concrete Laser Screed Boom type Leveling width 3850 outrigger length 6000 leveling, MACHMALL

Engineering & Construction Machinery > Road Construction & Maintenance Machinery > Motor Grader

ROADWAY Concrete Laser Screed Boom type Leveling width 3850 outrigger length 6000 leveling

View All >

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Stop selling Chat Now

Favorite Products

Product:

ROADWAY Concrete Laser Screed Boom type Leveling width 3850 outrigger length 6000 leveling

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

Specs & Compare

Details

Specifications

weight:11111.000kg
Condition:New
Moving Type:Other

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

Technical Parameters

Engine		Screed head
Model	Yanmar	Type	Laser self-leveling
Type	Diesel engine, liquid cooled, 4-stroke, four-cylinder	Width	3850mm
Power	63.9kw / 2500r / min	Paving type	With auger
Engine oil volume	10.2 / 5.7L	Auger force	Hydraulic motor
Fuel consumption	252g / kWh	Exciting force	3000N
Running device		Vibration frequency	60Hz
Driving	4 Hydraulic drive motor	Swing angle	± 45 °
Steering	Front wheel / four-wheel / crab-shaped turn	Screed head control	Ratio control
Wheel	Non-slip tire	Height of screed head	560mm
Outrigger	Self-levelling, four legs	Control accurary	± 1.5mm
Driving speed	0-8km / h	Operation mpde
Working speed	22m² / min	Chair position	Ride-on forward type
Laser control system		forward and reverse	Handle control, stepless speed walking
Control type	Microcomputer laser scan	Steering	Hydraulic intelligent control
Control effect	Flat, slope or double slope	Telescopic arm	Handle control, stepless speed walking
Cleaning system		Size and weight
Power	Hydraulic motor	Outline dimension	5600 × 4375 × 3575mm
The max. perssure of inlet	0.5MPa	Weight	8200kg
Fuel tank volume	150L
