XCMG factory 8m mini self propelled hydraulic scissor lift XG0807HDW

$10000.00-$1000000.00 1 / EA (Min. Order)
Model: XG0807HDW
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG factory 8m mini self propelled hydraulic scissor lift XG0807HDW

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Weight:1550kg
  • Overall Dimension:1900*830*2160mm
  • Table Size:1670*740mm
  • Max Lifting Height:7.8m
  • Min Lifting Height:1.05m
  • Rated Loading Capacity:230kg
  • Power:3.3kw
  • Lift Drive / Actuation:Hydraulic
  • Lift Mechanism:Scissor Lift
  • Model Number:XG0807HDW
  • Brand Name:XCMG
  • Place of Origin:Xuzhou, Jiangsu, China
  • Certification:CE/ISO9001

Specifications

  • Weight:1550.000kg
  • Condition:New
  • Moving Type:Other

XCMG factory 8m mini self propelled hydraulic scissor lift XG0807HDW

8m mini electric scissor lift aerial working platform XG0807HDW.



New scissor lift XG0807HDW developed by XCMG has the work height at 8m, the vehicle width at 0.78m, the rated load at 230kg, max. gradeability at 25%. This vehicle features compact structure, advanced performance, completed safety devices, especially suitable for construction. In addition, it is free of any pollution, with steady lifting / lowering, easy control and maintenance. Therefore, this kind of platforms are widely applied to warehouses, factories, airports, and train stations, especially the narrow work sites.

Advantages and features:


1.Effective and energy-saving electric-drive system features zero emission and low noise, together with the traceless tires, enabling this machine easily to work in enclosed environments such as office building, hospitals and schools and minimizing the effect on environment.



2.Active protective mechanism such as pothole protective mechanism and the self-developed safety control system feature the humanized design and the rich options, meeting the customer needing for safety, reliability and intelligence.



3.Narrow- structure design enables the complete vehicle to easily pass through a single gateway; foldable fence could make the transportation easier.



4."Zero Turning Radius "is unique and enable machine to corner in narrow room.



5.Max. payload at 230kg, leading the industry. Maximum traveling speed 4km/h and 25% gradeability make the driving easier.

XCMG factory 8m mini self propelled hydraulic scissor lift XG0807HDW

Item

Unit

Parameter

Dimension of machine Length (without ladder)

mm

1900(1680)

Dimension of machine Width

mm

830

Dimension of machine Height(platform folded)

mm

2160(1830)

Wheelbase

mm

1360

Wheel track

mm

660

Min. ground clearance (Pit protector ascending/descending)

mm

70/20

Dimension of working platform

Length

mm

1670

Dimension of working platform Width

mm

740

Dimension of working platform Height

mm

1235

Dimension of working platform Extension length of the auxiliary platform

mm

900

Centroid position of machine Horizontal distance to front shaft

mm

750

Centroid position of machine Height of centroid

mm

570

Total mass of machine

kg

1550

Max. height of platform

m

5.8

Min. height of platform

m

1.05

Max. working height

m

7.8

Minimum turning radius (inner wheel/outer wheel)

m

0/1.75

Rated load

kg

230

Payload of extended platform

kg

115

Lifting time

s

13-30

Lowering time

s

25-35

Drive speed(lowered)

km/h

3.9

Drive speed(elevated)

km/h

0.8

Max. gradeability

%

25

Tilt warning angle (side/forward and backward)

°

1.5/3

Lifting /traveling motor

Model

-

-

Lifting /traveling motor Rated power

kW

3.3

Lifting /traveling motor Manufacturer

-

-

Battery Model

-

T105/DT106/3-EV-225

Battery Voltage

v

24

Battery Capacity

Ah

225

Battery Manufacturer

-

Trojan/Leoch

Tire models

-

Traceless and solid/323×100
