• Product Name:G5BA0B1689E5BF
• Display online time:2019-12-27
• weight:285000.000kg
• After-sales Service Provided:Engineers available to service machinery overseas
• Warranty:12 Months
• Condition:NEW
• Moving Type:crawler
• Operation weight:285000kg
• Bucket capacity:15m³
• Rated power:1193/1800kW/rpm
• Bucket digging force:790kN
• Max. digging depth:8630mm

●Electric control and two-stage turbocharged mining engine has sufficient power.

●Electric control positive flow hydraulic system is high efficient and energy saving.

●Hydraulic buffering technology can realize realtime protection for crawler during travel.

●Closed rotating system is adopted to achieve more stable rotation and energy saving.

●Fully closed floating axle pins and mining heavy-load working device.

●Automatic lubrication system of whole machine has high lubrication efficiency.

●All-terrain concentrated fling system is adopted, the maintenance is convenient and fast.

●Automatic fire extinguishing system can guarantee the safe use of machine.

Description	Parameter	Unit
Operation weight	285000	kg
Bucket capacity	15	m³
Model	Cummins QSK50
Output power	1193/1800	kw/rpm
Traveling speed	2.0/1.5	km/h
Rotary speed	4	r/min
Grade ability	30	°
Ground pressure	198	kPa
Bucket digging force	790	Kn
Arm digging force	782	Kn
Main pump	4 plunger pumps
Rated flow	4x720	L/min
Main safty valve pressure	32	MPa
Standard configuration
Length of boom	9000	mm
Length of arm	4000	mm
Bucket capacity	15	m³
Apperance size	Parameter	Unit
Total lengtk	18170	mm
Length of crawler	8108	mm
Wheel base of crawler	6420	mm
Ground clearance of counter wehight	2247	mm
Total height	8470	mm
Total width	8007	mm
Track gauge	4900	mm
Width of crawler	1000	mm
Height of crawler	2165	mm
Working scope
Max. digging height	15100	mm
Max. dumping height	9900	mm
Max. digging depth	8630	mm
Max. horizontal clearance distance	8520	mm
Max. vertical digging depth	3000	mm
Min. swing radius	7980	mm
