XCMG Schwing Electric Concrete Mixer Truck G4802D China New Mobile Concrete Mixer Truck

$10000.00-$1000000.00 1 / EA (Min. Order)
Model: G4802D
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Schwing Electric Concrete Mixer Truck G4802D China New Mobile Concrete Mixer Truck

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications
  • 360-Degree VR Videos

Summary

  • Certification:CE/ISO9001
  • Dimension(L*W*H):10250X2525X3965mm
  • Weight:15050kg
  • Power(W):215KW
  • Model Number:G4802D
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China

Specifications

  • Weight:15050.000kg
  • Condition:New
  • Moving Type:Wheel

XCMG Schwing Electric Concrete Mixer Truck G4802D China New Mobile Concrete Mixer Truck

XCMG Schwing Electric Concrete Mixer Truck G4802D China New Mobile Concrete Mixer Truck.



XCMG electric concrete truck mixer inherits the classic design and in-novates with breakthrough.



Its chassis uses domestic well-known brandmotor, matching CATL 281kWh battery pack, fast power change device,5-minute power change can be realized.



The overall application of highstrength resistant board, aluminum alloy and non-metallic materials makesthe whole machine lighter.



Comprehensive optimization of mixing bladerealizes faster feeding, more uniform mixing and cleaner discharging; fullynew intelligent management platform, equipped with multi-media inter-net terminal, achieves digital management of electricity, material, peopleand vehicle, operation is safer and running cost is reduced.

XCMG Schwing Electric Concrete Mixer Truck G4802D China New Mobile Concrete Mixer Truck

Item

Parameter

Overall parameters

Max. gross mass kg

31000

Theoretical curb masskg

15000±3%

Outline dimensionmm

10350×2550×3965

 Driving type

8×4

Agitation volume

7.5

Rotary speed of mixing drum(r/min)

014

Feeding speed (m³/min)

3

Discharging speed (m³/min)

2

 Discharge remnant percentage

0.5

Mileage

About 180km

Chassis parameters

Driving cab

G5 driving cab

Transmission

Fast AMT 6 gear

Rear axle

Hande 25 axle (11.5t)

Car body

280×80×(8+5)mm

Suspension

9/9/13

Front axle

2020 front axle, drum-type braking, ABS self-regulating arm

Wheel

11.00R20

Steering

Φ110mm steering engine

Electric motor

Brand

Fast permanent magnet synchronous motor

Rated/peak power

215/360kW

Rated/peak torque

1200/2800Nm

Battery

Brand

CATL

Voltage

618.24V

Electric quantity

281kWh

Charging time

The fastest charging time for tow guns is one hour

Size parametersmm

Wheelbase

1950+2900+1350

Front/rear suspension

1300/1400

Front/rear wheel track

2060/1860

Mass parameterskg

Chassis dead-weight

11300

Performance parameters

Max. driving speedkm/h

85

Max. gradeability%

50

Drum parameters

Geometrical capacity

15.5

 Drum length mm

5255

Diameter/tilt angle of mixing drummm/°

2280/15

Water tank

Volume

300L Aluminium alloy
