XCMG Official GR2153 Motor Grader for sale, MACHMALL

Engineering & Construction Machinery > Road Construction & Maintenance Machinery > Motor Grader

XCMG Official GR2153 Motor Grader for sale

View All >

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Official GR2153 Motor Grader for sale

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Dimension(L*W*H)

Weight

Model Number

Brand Name

Place of Origin

Reverse Speed(km/h)

Forward Speed(km/h)

Certification

Engineering & Construction Machinery

8970 x 2625 x 3420mm

16500kg

GR2153

XCMG

China

5、11、23km/h

5、8、11、19、23、38km/h

Can provide relevant certification

+ Add a Product

Summary

Dimension(L*W*H):8970 x 2625 x 3420mm
Weight:16500kg
Model Number:GR2153
Brand Name:XCMG
Place of Origin:China
Reverse Speed(km/h):5、11、23km/h
Forward Speed(km/h):5、8、11、19、23、38km/h
Certification:Can provide relevant certification

Specifications

weight:16500.000kg
Condition:New
Moving Type:Wheel
Engine model:QSB6.7
Rated power/speed:164kW/2000rpm
Tire specification:17.5-25
Ground clearance (front axle):430mm
Space of front and rear axles :6219 mm
Tractive effort f=0.75:≥85kN
Working system pressure:20MPa
Maximum steering angle of front wheel:±48°
Minimum turning radius:7.3m
Maximum lift height:400mm
Maximum shoveling depth:500mm

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG Official GR2153 Motor Grader for sale

	Item		Unit	GR2153
Basic parameters	Engine model			QSB6.7
	Rated power/speed		kW/rpm	164/2000
	Overall dimension(standard)		mm	8970 x 2625 x 3420
	Total weight(standard)		kg	16500
	Tire specification			17.5-25
	Ground clearance		mm	430
	Tread		mm	2156
	Space of front and rear axles		mm	6219
	Space of middle and rear wheels		mm	1538
Performance parameters	Forward velocity		km/h	5、8、11、19、23、38
	Reverse speed		km/h	5、11、23
	Tractive effort f=0.75		kN	≥85
	Maximum gradeadbility		%	≥25
	Inflation pressure of tires		kPa	260
	Working system pressure		MPa	20
	Transmission pressure		MPa	1.3-1.8
Working parameters	Maximum steering angle of front wheels		°	±48
	Maximum inclination angle of front wheels		°	±17
	Maximum swing angle of front axle		°	±15
	Maximum swing angle of balance box		°	front 15, rear 15
	Maximum steering angle of frame		°	±27
	Maximum turning radius		m	7.3
	Blade	Maximum lifting height	mm	400
		Maximum shoveling depth	mm	500
		Maximum lateral inclination angle	°	90
		Cutting angle	°	28-70
Oil filling amount		Slewing angle	°	360
		Length x chord height	mm	3965 x 610
	Coolant		L	50
	Fuel tank		L	280
	Engine		L	24
	Transmission		L	38
	Balance box		L	46
	Drive axle		L	28
	Hydraulic oil		L	110

XCMG Official GR2153 Motor Grader for sale
