XCMG new 550HP motor graders GR5505 Chinese grader motor road construction equipment for sale
Summary
- Weight:63000kg
- Dimension(L*W*H):14300*4200*4600mm
- Power(W):399kw
- Model Number:GR5505
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Grade Ability:25%
- Travel Speed:42.7km/h
- Certification:CE/ISO9001
Specifications
- weight:63000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG new 550HP motor graders GR5505 Chinese grader motor
road construction equipment.
The motor
grader is mainly used for ground leveling, ditching, slope scraping,
bulldozing, scarification, snow removal for large areas such as highway,
airports, farmlands etc.
1. The
friction-disc worm gearbox with overload protection is developed for the mining
heavy load condition, which can slip automatically and protect the safety of
the machine and personal.
2. Load
sensing hydraulic system is equipped with variable piston pump and load sensing
multi-way valve, which improve operation comfort, the pilot independent
electrical proportional valve, the main directional valve and relief valve are
proportional valves.
3. The
service brake is a double-loop hydraulic braking system.
4. The
same time using ROPS&FOPS cabin to meet ISO standard. Equipped with air
conditioning, adjustable suspension seat, equipped with wipers and defrosting
vents to improve the comfort of operation.
5.
Spacious cabin design, three-dimensional air duct, good driving experience.
Double handle operation can be selected on the handle operation, reducing the
labor intensity by about 80%.
|
Model |
GR5505 |
||
|
Engine |
Engine model |
QSX15 |
|
|
Rated power/speed |
kw/rpm |
399/2100 |
|
|
Traveling speed
forward |
km/h |
4.7/6.2/9.1/11.9/17.3 |
|
|
/22.5/33/42.7 |
|||
|
Performance |
Traveling speed
reverse |
km/h |
4.7/0.1/17.3/33 |
|
(f=0.75)Tracliveforce |
kN |
380 |
|
|
Max.gradeability |
% |
25 |
|
|
Min.turning radius
using articulation |
m |
7.3 |
|
|
Maximum lift above
ground |
mm |
450 |
|
|
Operating
specification |
Maximum depth of
cutting |
mm |
500 |
|
Maximum blade position
angle |
° |
90 |
|
|
Blade cutting angle |
° |
28~70 |
|
|
Blade |
Circle reversing
rotation |
° |
360 |
|
Molo board width x
height |
mm |
7300 1607 |
|
|
Dimension(LxWxH) |
mm |
14300*4200*4600 |
|
|
Operating
weight(Standard) |
kg |
63000 |
|
