XCMG Official XDA40 China New 40 Ton Articulated Dump Truck for Mine

$10000.00-$1000000.00 1 / EA (Min. Order)
Model: XDA40
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official XDA40 China New 40 Ton Articulated Dump Truck for Mine

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Certification:CE/ISO9001
  • Dimension(L*W*H):10690*3370*3793mm
  • Weight:73t
  • Power(W):350KW
  • Model Number:XDA40
  • Place of Origin:Jiangsu,China
  • Max. Speed:60km/h
  • Loading Height:3180mm
  • Brand Name:XCMG

Specifications

  • weight:73000.000kg
  • Condition:New
  • Moving Type:Other

XCMG Official XDA40 China New 40 Ton Articulated Dump Truck for Mine

XCMG Official XDA40 China New 40 Ton Articulated Dump Truck for Mine.



Dump truck XDA40 adopts mine-specific heavy-duty working device and chassis system; the power system is highly energy-saving and meets the emission regulations of different regions such as China Phase IV, North America Tier4F, European StageV, etc., suitable for the global market; newly designed comfortable positive pressure cab, advanced control system and behavior Monitoring system, more comfortable driving and smarter operation



1. High efficiency: The original imported engine has strong power, meets the requirements of efficient operation and low fuel consumption.



2. High efficiency and energy saving: the use of pump-controlled hydraulic system and load-sensitive steering system improves the stability of the system and the convenience of troubleshooting, making it more efficient and energy-saving.



3. Intelligence: Apply XCMG's unique driving control strategy, develop unique shift control programs and fault diagnosis system, and make the whole vehicle more intelligent.



4. High reliability: 6×6 drive and friction plate type inter-wheel and inter-axle differential lock, which makes the vehicle passability, reliability and driving stability reach a higher level.



5. Comfort and safety: ROPS&FOPS cab equipped with ISO anti-tip/anti-falling object standards is equipped with spacious space, wide vision, and a more comfortable and safe driving environment.



6. High maintainability: Both the cab and the hood are designed to be reversible. The whole vehicle is equipped with centralized lubrication system, centralized filling, centralized sampling and other systems, which are convenient and efficient for maintenance.

XCMG Official XDA40 China New 40 Ton Articulated Dump Truck for Mine

Item

Unit

XDA40

Dimension

Overall Length

mm

10690

Overall Width

mm

3370

Overall Height

mm

3793

Wheelbase front-mid

mm

4450

Wheelbase mid-rear

mm

1940

Tire center distance

Front

mm

2600

Mid & Rear

mm

2600

Weight

Total Weight

kg

73000

Payload

kg

39000

Curb Weight

kg

34000

Weight Distribution

Unload

Front

kg

17000 (50%)

Mid & Rear

kg

17000 (50%)

Loaded

Front

kg

21600 (29.6 %)

Mid & Rear

kg

51400 (70.4%)

Power Train

Engine

/

Benz OM502

Rated Power

kW/HP/rpm

350/1800

Max Torque

Nm/rpm

2300/1300

Drive

/

6×6

Tires

/

29.5R25

Driving Performance

Max speed

km/h

60

Min Turning Clearance

mm

8865

Max Grade ability

%

45

Max Steering Angle

°

±45

Minimum Ground Clearance

mm

565

Working Parameter

Loading Height

mm

3180

Hoist Time

s

12

Hoist Angle

°

70
