XCMG 400 Ton Hydraulic Underground Mining Excavator Equipment XE4000 Price

Chat Now 1 / EA (Min. Order)
Model: XE4000
Engine: Cummins
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG 400 Ton Hydraulic Underground Mining Excavator Equipment XE4000 Price

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

Specifications

  • Weight:390000.000kg
  • Condition:New
  • Moving Type:Crawler
  • Bucket capacity:22m3
  • Operating Weight:390000kg
  • Maximum Digging Depth:8340mm
  • Maximum Digging Height:17160mm
  • Brand Name:XCMG
  • Place of Origin:China

XCMG 400 Ton Hydraulic Underground Mining Excavator Equipment XE4000 Price

XCMG 400 Ton Hydraulic Underground Mining Excavator Equipment XE4000.



The XE series of underground mining excavator bring you an extraordinary driving experience with lean manufacturing, professional design and excellent reliability. Moreover, this series of products boast strong excavating power and quick operating speed, making them have matchless operating performance and economic efficiency even in severe mining condition.



1. Engine

XE4000 introduces Cummins full EC engine and double-stage turbo-charging technology. Equipped with the advanced modularized common rail fuel system (MCRS), the engine features sufficient power and high fuel economy.



2. Low-temperature cooling

Low-temperature after-cooling system LTA is used to ensure the intake temperature, which greatly prolong the engine block's service life



3. Multi-pump combined control

By virtue of this function, the product realizes the optimal flow distribution in combined operation, so that it could have more coordinate operability and higher working efficiency.

XCMG 400 Ton Hydraulic Underground Mining Excavator Equipment XE4000 Price

Description

Parameter

Unit

Model

Operation weight

390000

kg

Bucket capacity

22

Engine

Model

-

QSK60C

Rated power / rotating speed

1491/1800

kw/rpm

Maximum torque / speed

8906/1500

N.m

Main performance

Traveling speed

2.5/1.9

km/h

Rotary speed

3.5

r/min

Grade ability

30

°

Ground pressure

260

kPa

Bucket digging force

1159

Kn

Arm digging force

1125

Kn

Dimension

Total length

20000

mm

Total height

8535

mm

Total width

9470

mm

Total chassis width

6910

mm

Width of crawler

1000

mm

Track wheelbase

6660

mm

Min. ground clearance

985

mm

Operating range

Max. digging height

17160

mm

Max. dumping height

11825

mm

Max. digging depth

8340

mm
