XCMG new 82 ton multi-function rotary drilling rig China hydraulic drill rigs XR240E (Euro Stage IV)

$10000.00-$1000000.00 1 / EA (Min. Order)
Model: XR240E
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG new 82 ton multi-function rotary drilling rig China hydraulic drill rigs XR240E (Euro Stage IV)

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Certification:CE/ISO9001
  • Weight:82000kg
  • Model Number:XR240E
  • Brand Name:XCMG
  • Place of Origin:China
  • Power Type:Diesel
  • Type:Rotary Drilling Rig

Specifications

  • Weight:82000.000kg
  • Condition:New
  • Moving Type:Other
  • Overall working height:22.7m
  • Crawler width:3250-4400mm

XCMG new 82 ton multi-function rotary drilling rig China hydraulic drill rigs XR240E (Euro Stage IV)

XCMG new 82 ton multi-function rotary drilling rig China hydraulic drill rigs



XR Series Rotary Drilling Rig stands for our company's achievement in many years' development and researches on piling machines, adopting advanced technology, both at home and abroad. With our company's powerful machinery manufacturing capacity, it is specially designed to drill the pile hole with the big diameter and into hard—layers, fitting for layer conditions in most areas.



Performance Characteristics:

1. As a multi-function machine, it can realize the quick switching of functions such as cylinder pressurization, crowd winch pressurization, oscillator, CFA, and dual powerhead;



2. The capacity of the rotary drive and the main winch is increased by 20% and the work efficiency is higher;



3. The rotary drive can be equipped with a torque multiplier (optional). The casing drive torque is up to 360kN-m and the casing construction ability is stronger;



4. The main and auxiliary winches both adopt single-layer rope technology. The service life of the wire rope is 24 times longer than that of the multi-layer rope and the cost is lower;



5. The double jib parallelogram luffing mechanism has a large support angle and a 16% increase in the support range. The operation a more stable;



6. The hydraulic system adopts negative flow control technology which has a fast response and good control performance;



7. The independent high-power rate temperature-controlled hydraulic oil cooler is suitable for high-temperature construction and can adjust fan speed with temperature changes;



8. Intelligent control system can automatically adjust and display the verticality of the mast, automatically slew and slag discharge, CFA model automatically lifting concrete pouring and pile type display. The system uses a bus panel design to prevent misoperation.

XCMG new 82 ton multi-function rotary drilling rig China hydraulic drill rigs XR240E (Euro Stage IV)

Item

Unit

Parameters

Working capacity

Max diameter

mm

Φ2200mm(Crowd Cylinder)

Φ2000mm(Crowd Winch)

Max depth

m

70

Engine

Model

-

Volvo TAD1171VE

Rated power

kw

265

Tank volume

L

580

Rotary drive

Max torque

kN.m

240

Speed

r/min

7-30

Working condition

Overall working height

m

22.7

Overall working weight

t

82

Crawler

Crawler width

mm

3250-4400

Shoes width

mm

800

Shoes length

mm

5715

Driving force

kN.m

485

Travel speed

km/h

0-1.8

Mast

Lateral

°

4

Forward

°

5

Crowd cylinder

Max crowded force

kN

210

Max extraction force

kN

220

Stroke

mm

5000

Slow speed

m/min

5.8

High speed

m/min

12

Crowd winch (optional)

Max crowded/ extraction force

kN

250/250

Stroke

m

13

Slow speed

m/min

7

High speed

m/min

30

Diameter of ropes

mm

24

Main winch

Max extraction force

kN

240

Speed

m/min

0-70

Diameter of ropes

mm

32

Auxiliary winch

Max extraction force

kN

80

Speed

m/min

0-70

Diameter of ropes

mm

20

Hydraulic system

Max flow

L

2x280+90

Max working pressure

Mpa

34
