Summary
- Size:300×80×8mm
- Model Number:NXG4250D3WC
- Brand Name:XCMG
- Place of Origin:China
- Certification:ISO9001
Details
- Product Name:357636-NXG4250D3WC
- Display online time:2019-11-14
- weight:1000.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:other
- Drive type:6×4
- Wheelbase(mm):3800+1400mm
- Engine Type:WP12.380NE32
- Engine rated output:280/1900kw/rpm
- Engine max torque:1700/1200-1400Nm/rpm
- Engine emission standard:EURO Ⅲ
- Engine fuel tank:400L
- Transmission Type:16JSD200TA
- Transmission Ratio:14.03-0.83
- Axle system(Front axle/Middle axle/Rear axle):6.5/13/13t
- Suspension leaf spring:3/4
- Suspension blanced suspension:Integral
- Longitudinal beam(height×width×thickness):300×80×8mm
- Tire Type:12R22.5
- Brake system:Drum
- Brake system(ABS):equipped
- Fifth wheel:50#
- Sound box:Equipped
- Cab series:HANVAN G7
- Cab left/Right driving:LHD
- Cab front suspension:Air bag
- Cab rear suspension:Air bag
- Cab seats:Air bag seats
- Cab bunk:Equipped
- Cab window regulator:Electric
- Cab rear window:Equipped
Description | Parameter value | ||
Main paramet | Drive type | 6×4 | |
Wheelbase(mm) | 3800+1400 | ||
Engine | Type | WP12.380NE32 | |
Rated output (kw/rpm) | 280/1900 | ||
Max torque(Nm/rpm) | 1700/1200-1400 | ||
Emission standard | EURO Ⅲ | ||
Fuel tank(L) | 400 | ||
Transmission | Standard | Type | 16JSD200TA |
Ratio | 14.03-0.83 | ||
Axle system | Front axle | 6.5t | |
Middle axle | 13t | ||
Rear axle | 13t | ||
Suspension | Leaf spring | 3月4日 | |
Blanced suspension | Integral | ||
Frame | Longitudinal beam(height×width×thickness)/mm | 300×80×8 | |
Tire | Type | 12R22.5 | |
Brake system | Brake | Drum | |
ABS | equipped | ||
Body | Fifth wheel | 50# | |
Box/Lifting | / | ||
Electrical system | Sound box | Equipped | |
Cab | Series | HANVAN G7 | |
Left/Right driving | LHD | ||
Front suspension | Air bag | ||
Rear suspension | Air bag | ||
Seats | Air bag seats | ||
Bunk | Equipped | ||
Window regulator | Electric | ||
Rear window | Equipped | ||
Air conditioning | Equipped |
Response Time : Within 24 hours
Xuzhou Construction Machinery Group Co., Ltd. (XCMG) was founded in 1943. Since then, XCMG has stood at the forefront of the Chinese construction machinery industry and developed into one of the domes
