XCMG official QY25K5A_Y 25 ton Chinese truck crane for sale
FOB for Cranes Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: QY25K5A_Y
Engine: SHANGCHAI
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG official QY25K5A_Y 25 ton Chinese truck crane for sale
XCMG official QY25K5A_Y 25 ton Chinese truck crane for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:QY25K5A_Y
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Max. Lifting Height:55m
  • Max. Lifting Load:25 ton
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:29400.000kg
  • Condition:New
  • Moving Type:Wheel
  • Engine rated power:213/2200kw/(r/min)
  • Engine rated torque:1200/1400N.m/(r/min)
  • Max. travel speed:90km/h
  • Min. turning diameter:22m

XCMG official QY25K5A_Y 25 ton Chinese truck crane for sale

XCMG official QY25K5A_Y 25 ton hydraulic truck crane.



XCMG truck crane QY25K5A_Y is the product with high reliability inheriting XCMG classical and advanced technology aboutdesign and manufacture truck crane of many years and based on mature technology.



XCMG truck crane QY25K5A_Y all covered working surface and new appearance outline are equipped. The operations of craneare very simple, convenient and flexible. XCMG truck crane QY25K5A_Y is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oil field, industrial and mining enterprises, etc.



Performance Characteristics:



1. U-shaped cross-section boom has small depth-width ratio, strong bearing capacity, small deformation, strong anti bending and powerful lifting capacity.



2. Plug-in boom head effectively increases the boom connect length and reduces boom deformation. Embedded sliders are equipped, which enlarge the contact square and reduce the contact stress of boom.



3. With 9-speed transmission equipped, it has superior travel and grade ability.

XCMG official QY25K5A_Y 25 ton Chinese truck crane for sale

Category
Item
Unit
Parameter
Outline Dimensions
Overall length
mm
12680
Overall width
mm
2500
Overall height
mm
3400
Axle base
mm
4425+1350
Wheel base
mm
2074/1834/1834
Weight
Total vehicle mass in travel configuration
kg
32800
Power
Model

SC9DF290Q4
Rated power
kw/(r/min)
213/2200
Rated torque
N.m/(r/min)
1200/1400
Travel Performance
Max. travel speed
km/h
90
Min. turning diameter
m
22
Min. ground clearance
mm
275
Approach angle
°
11
Departure angle
°
12
Braking distance(at 30 km/h)
m
≤10
Max. grade ability
%
41
Oil consumption per 100km
L
≤32
Noise
Exterior noise level in accelerating
dB(A)
88
Noise Level at seated position
dB(A)
90
