XCMG 5 ton bucket loader LW500FN with catalog PDF

$35000.00-$55000.00 1 / EA (Min. Order)
Model: LW500FN
Engine: WEICHAI
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG 5 ton bucket loader LW500FN with catalog PDF

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF

Summary

  • Rated Load:5000kg
  • Dimension(Long* Breadth * High):7910*3016*3515mm
  • Type:front loader
  • Place of Origin:Xuzhou, Jiangsu, China
  • Model Number:LW500FN
  • Brand Name:XCMG
  • Certification:CE/ISO90001

Specifications

  • Weight:16900.000kg
  • Engine Brand:WEICHAI
  • Rated Load:6-10 ton
  • Bucket Capacity:2.5 - 3.5m³
  • Power:162KW
  • Bucket capacity:2.5~4.5m3
  • Max. breakout force:170KN
  • Machine Weight:16900kg
  • Wheel base:2960mm

XCMG 5 ton bucket loader LW500FN with catalog PDF

XCMG 5 ton bucket loader LW500FN.



XCMG bucket loader LW500FN boasts outstanding advantages (such as efficiency) in the fields of engineering constructions, aggregate yards, and coal logistics.



XCMG bucket loader LW500FN is the latest cross-generation product developed by XCMG on the basis of the globalized technologic resources.



Performance Highlights:



1. XCMG bucket loader LW500FN featuring high carrying capacity and working stability.



2. ≥7 ,500kg lifting capacity and 170kN breakout force handle all kinds of materials with ease.



3. XCMG bucket loader LW500FN has 160kN traction force and ≥3. 5m high dumping capacity handle the severe conditions with ease.



4. With short wheelbase and small turning radius, this product features high mobility and flexibility and outstanding field adaptability.





XCMG bucket loader LW500FN Variety attached tools meeting requirements of different working conditions:



Clipping plier I (paired teeth)/ Clipping plier II (staggered teeth)/ Toad's mouth clamp/ Port plier/ Grasping grass machine/ Pallet fork/ Snowplow.

XCMG 5 ton bucket loader LW500FN with catalog PDF

Description
Unit
Parameter value
Rated operating load
kg
5000
Bucket capacity
2.5~4.5
Machine weight
kg
16900
Dump clearance at maximum lift
mm
3150~3560
Reach at maximum lift
mm
1100~1190
Wheel base
mm
2960
Tread
mm
2250
Height of hinge at maximum lift height
mm
4112
Working height(fully lifted)
mm
5510
Max.breakout force
kN
170
Hydraulic cycle time-raise
s
≤6
Total hydraulic cycle time
s
≤10.5
Min. turning radius over tyres
mm
5950
Articulation angle
°
35
Gradeability
°
28
Tyre size

23.5-25-16PR
Overall machine dimension L×W×H
mm
7910×3016×3515
Model

WD10G220E21
Rated Power
kW
162
Fuel Tank
L
250
Hydraulic Tank
L
210
Travel Speed
Ⅰ-gear(F/R)
km/h
13/18
Ⅱ-gear(F/R)
km/h
40
