XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig for sale
FOB for Piling Mach Reference Price:Get Latest Price
$100000.00-$150000.00 1 / EA (Min. Order)
Model: XR150DIII
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig for sale
XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
  • Product Brochure
Summary
  • Dimension(L*W*H):7550*4200*19040mm
  • Weight:49ton
  • Power(W):150kw
  • Model Number:XR150DIII
  • Brand Name:XCMG
  • Place of Origin:XUHZOU, CHINA
Details
  • weight:49000.000kg
  • Condition:New
  • Moving Type:Other

XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig for sale

XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig.



1. XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig adopts the dedicated hydraulic retractable crawler chassis and large diameter slewing bearing to provide extraordinary stability and transport convenience.



2.  It adopts the Cummins electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.



3. With the hydraulic pressure system adopted threshold power control and negative flow control, the system acquired high efficiency and higher energy conservation.



4. Using single rope winding, effectively solve the steel wire rope wear problem, improve the life of wire rope; And drill deep detection device is settled in main winding, single rope to make deep inspection more accurate.



5. The whole machine design meet the requirements of the CE directive, safety guarantee, construction safer.



XCMG XR150DIII foundation drilling equipment 160kN 56m rotary drilling rig for sale

Description

Unit

XR150DIII

Max. drilling diameter

mm

1500

Max. drilling depth

m

56

Allowable luffing scope (from center of drill rod to slewing center)

mm

32503650

Drilling rig dimension in working condition (L × W × H)

mm

7550×4200×19040

Drilling rig dimension in transport condition (L × W × H)

mm

13150×2960×3140

Weight of overall unit (standard configuration, excluding drilling tool)

t

49

Engine

Model



CUMMINS QSB7



Rated power/speed

kW

150/2050r/min

Max. working pressure of hydraulic system

MPa

35

Rotary drive

Max. torque

kN •m

150



Rotational speed

r/min

733

Crowd cylinder

Max. Pushing force

kN

120



Max. Pulling force

kN

160



Max.stroke

mm

3500

Main winch

Max.pulling force

kN

160



Max. single-rope speed

m/min

72



Diameter of the steel wire rope

mm

26

Auxiliary winch

Max.pulling force

kN

50



Max. single-rope speed

m/min

60



Diameter of the steel wire rope

mm

16

Rotary table slewing angle

°

360

Traveling

Max. traveling speed of the overall unit

km/h

2.1



Max. climbable gradient of the overall unit

%

40

Crawler

Width of crawler plate

mm

700



External width of crawler (min.-max.)

mm

29604200



Center distance between two longitudinal wheels of crawler

mm

4310



Average ground pressure

kPa

83
