XCMG mobile concrete placing boom 28 meters radius HGP28 price

  • XCMG mobile concrete placing boom 28 meters radius HGP28 price
  • XCMG mobile concrete placing boom 28 meters radius HGP28 price
  • XCMG mobile concrete placing boom 28 meters radius HGP28 price
  • XCMG mobile concrete placing boom 28 meters radius HGP28 price
  • XCMG mobile concrete placing boom 28 meters radius HGP28 price

Share:
XCMG mobile concrete placing boom 28 meters radius HGP28 price
FOB for Concrete Mach Reference Price:Get Latest Price
$100000.00-$200000.00 1 / EA (Min. Order)
Model: HGP28
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG mobile concrete placing boom 28 meters radius HGP28 price
XCMG mobile concrete placing boom 28 meters radius HGP28 price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Certification:CE/ISO9001
  • Power(W):22000W
  • Model Number:HGP28
  • Brand Name:XCMG
  • Place of Origin:Jiangsu,China
Details
  • weight:1.000kg
  • Condition:New
  • Moving Type:Other
  • Max. placing radius:28m
  • Independent height:21m
  • Climbing speed:0.5~0.8m/mim
  • System pressure:33MPa

XCMG mobile concrete placing boom 28 meters radius HGP28 price

XCMG mobile concrete placing boom 28 meters radius HGP28.



XCMG mobile concrete placing boom HGP28 is a kind of equipment used together with concrete pump, which can rise inside building and realize ideal concrete placement,its max. placing radius is 28 meters. XCMG mobile concrete placing boom HGP28 is researched and developed by incorporating advanced SCHWING technology of placing boom and adopting such design method as finite element analysis.


Automatic climbing technology
Now, most placing booms in the market adopt cylinder jacking for climbing. The automatic climbing system of SCHWING placing boom has been tested by the market. The adoption of this climbing technology is good for our company to form products and enter into the market rapidly. The accumulation of relevant experience has laid a foundation for developing an automatic climbing system of better performance and stronger operability.

External linkage of concrete pump truck boom
External linkage is also one of the typical marks in integrating SCHWING technology. The design of "Front Two, Rear Three" structural type external linkage has effectively improved the problem of boom transverse swing. The optimization of connecting pin roll fixing ways has ensured the distance between booms, avoided possibly existing interference problem and guaranteed reliability.

* Full filtering
All loop tanks are equipped with full filtering system of oil suction and oil return which ensures system cleanness, prolongs service life of hydraulic elements and hydraulic oil, and generates higher operational reliability of hydraulic system.

XCMG mobile concrete placing boom 28 meters radius HGP28 price

Description

Unit

Parameter value

Max. placing radius

m

28

Slewing angle of the placing boom

°

370

Independent height

m

21

Mounting type



Floor

Climbing speed

m/mim

0.5~0.8

Climbing type



Top-climbed oil tank

Motor model



YX3-180L-4 V1

Power

Kw

22

Rev.

rpm

1470

System pressure

MPa

33

Flow

L/min

34

Oil tank capacity

L

120

Control mode



Panel control/wired control/remote control

Cleaning methods of delivery pipe



Washing/dry cleaning

Gross mass (including counterweight)

mm

21

Boom type

mm

4R

Delivery pipeline diameter

mm

DIN125

Length of end hose

m

3

XCMG mobile concrete placing boom 28 meters radius HGP28 priceXCMG mobile concrete placing boom 28 meters radius HGP28 priceXCMG mobile concrete placing boom 28 meters radius HGP28 priceXCMG mobile concrete placing boom 28 meters radius HGP28 priceXCMG mobile concrete placing boom 28 meters radius HGP28 priceXCMG mobile concrete placing boom 28 meters radius HGP28 price
