China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale

  • China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
  • China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
  • China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
  • China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
  • China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale

Share:
China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
FOB for concrete pump Reference Price:Get Latest Price
$100000.00-$125000.00 1 / EA (Min. Order)
Model: HBC80-11-110
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Weight:11000kg
  • Power(W):110KW
  • Model Number:HBC80-11-110
  • Brand Name:ShuoLi
  • Place of Origin:Jiangsu,China
Specifications
  • weight:11000.000kg
  • Condition:New
  • Moving Type:Wheel
  • Color:Color
  • Wheelbase:1250/2560mm
  • Loading height:1350mm
  • Hydraulic system pressure:32Mpa

China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale



China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110.



Strong power: the main engine adopts famous brand diesel engine;



High-quality hydraulic components: main oil pumps and valves are sampled from famous brand products such as German Rexroth;



Advanced hydraulic system: use open circuit, electro-hydraulic reversing system;



Equipped with high and low pressure switching valve: the working state of the pump can be adjusted at will according to the construction requirements, no need to disassemble the oil pipe to avoid system pollution;

China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale

Parameter

Unit

HBC80-11-110

Maximum concrete conveying volume

m3/h

80

Maximum pumping concrete pressure

Mpa

11

Main cylinder bore×cylinder rod×stroke

mm

φ125×φ80×φ1650

Conveying cylinder bore×stroke

mm

φ230×1650

Hydraulic system pressure

Mpa

32

Loading height

mm

1350

Main power

kW

110

Number of commutations

Times/min

21

Power system speed

r/min

1480

Model



EQ1108Z46D1

Deadweight

kg

5000

Vehicle weight

kg

11000

Maximum speed



90

Maximum power

Kw

100

Maximum grade



27

The number of passengers in the cab



3

Fully loaded front axle

kg

3020

Fully loaded rear axle

kg

6630

Front suspension and back suspension

mm

4700

Wheelbase

mm

1250/2560

Tire specifications



8.25-20-14PR



China shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for saleChina shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for saleChina shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for saleChina shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for saleChina shuoli 80m3/h truck mounted pump for concrete HBC80-11-110 for sale
