FOB Price: $10000.00-$100000.00
View All >
Model: QY50KA
Engine: HANGFA
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG QY50KA 50 ton mobile truck crane price
XCMG QY50KA 50 ton mobile truck crane price
Quantity:
- + /EA

Content:

Or choose from these questions:
What is the best price you can offer?
Do you support customization?
What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

QY50KA
Specs & Compare
Details
VR
Specs & Compare
Select 3 models for comparison
Model Number
Brand Name
Place of Origin
Span
Max. Lifting Height
Max. Lifting Load
Rated Lifting Moment
Rated Loading Capacity
Application
Certification
Engineering & Construction Machinery
QY50KA
QY50KA
XCMG
Xuzhou,Jiangsu,China
6.9m
58.1m
50 ton
2009kN.m
50 ton
Construction
CE/ISO9001
+   Add a Product
+   Add a Product

Summary

  • Model Number:QY50KA
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:6.9m
  • Max. Lifting Height:58.1m
  • Max. Lifting Load:50 ton
  • Rated Lifting Moment:2009kN.m
  • Rated Loading Capacity:50 ton
  • Application:Construction
  • Certification:CE/ISO9001

Specifications

  • weight:42200.000kg
  • Condition:New
  • Moving Type:Wheel
  • Engine rated power:276/2200kw/(r/min)
  • Engine rated torque:1500/1300-1600N.m/(r/min)
  • Max. travel speed:85km/h
  • Max. grade ability:0.42
  • Wheel base:2304+2075mm

Packaging & Shipping

  • Delivery Lead Time:7 days for ready goods
  • Minimum Order:1 Piece
  • Supply Ability:10,000 Set/ Sets per Month
  • Total Quantity In Stock:Over 5000
  • Delivery Port:Any Port In China

XCMG QY50KA 50 ton mobile truck crane price

XCMG QY50KA 50 ton mobile truck crane.



XCMG 50 ton truck crane QY50KA structure is compact, the industry operating performance is the highest. Lifting performance and driving performance of a comprehensive upgrade, leading competitors. Dual-pump confluence technology, operating efficiency of a comprehensive lead.



Advantages and highlights:



1. Leading lifting and driving performances

* XCMG 50 ton crane QY50KA Five section U-type booms. The boom length is 11.4m-43.5m with strong lifting performance, leading 5%-10% ahead of products with the same tonnages in the same industry.

* High-power engine with good dynamic performance, strong gradeability and superior trafficability. The maximum gradeability and maximum travel speed respectively are 42% and 85km/h.



2. Reliability of heat dissipation, electrical system etc. has been improved with safer operation and driving

* Waterproof connector clip is equipped with rubber sheath inside with excellent water impervious and level of protection reaches to IP65.

* The air-conditioning condenser is separately installed, the heat-sinking capability is sharply improved and the environment temperature reached to more than 45℃.



3. Mature and reliable double-pump confluence technique, maintaining the advantages of efficient operation

* XCMG 50 ton crane QY50KA double-pump confluence technique is adopted in raising and falling of winch, extending and retracting of lazy boom and luffing, leading ahead of luffing and extending and retracting operations.



4. Air-aid shift gears and 45% of shifting force is reduced

* XCMG QY50KA crane's boost system will work only by stepping on the clutch that effectively avoids gearbox damaging gears when shifting. Compared with the same industry, 100mm distance of shift gears and 45% of shifting force are respectively reduced.

XCMG QY50KA 50 ton mobile truck crane price

Description
Unit
Parameter value
Overall length
mm
13930
Overall width
mm
2780
Overall Height
mm
3630
Axle base
1st ,2nd axle
mm
1470
2nd ,3rd axle
4300
3rd ,4th axle
1350
Wheel Base
mm
2304+2075
Front overhang/rear overhang
mm
2389/2064or 2376/2064
Front extension/rear extension
mm
2131/226 or 2144/226
Total vehicle mass in travel configuration
kg
42200
Axle load
Front axle
kg
16200
Rear axle
26000
Engine Model

WD615.338
Engine rated power
kw/(r/min)
276/2200
Engine rated torque
N.m/(r/min)
1500/1300-1600
Max. travel speed
km/h
85
Min. steady travel speed
km/h
2~3
Min. turning diameter
m
24
Min. ground clearance
mm
327
Max. grade ability
%
42
Approach angle
°
19
Departure angle
°
15
Braking distance (at 30 km/h, full load )
m
≤10
Oil consumption per 100km
L
40
Exterior noise level during acceleration traveling
dB (A)
≤88
Noise level at seated position
dB (A)
≤90
