XCMG Official 40ton Minging Dump Truck XDA40 Articulated Dump Truck Price For Sale
.jpg)
Summary
- Certification:ISO/CE9001
- Dimension(L*W*H):10690*3370*3793mm
- Weight:34000kg
- Power(W):350KW
- Model Number:XDA40
- Place of Origin:JiangSu,China
- Max. Speed:60
- Loading Height: 3180mm
- Brand Name:XCMG
Specifications
- Weight:34000.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 40ton Minging Dump Truck XDA40 Articulated
Dump Truck.
XDA40
ADT adopts XCMG proprietary real-time six-wheel drive technology, all-terrain
self-adaptive driving technology, integrated control technology for safe
driving and riding, thermal energy control and management technology, stability
control technology for large flow hydraulic dump system, intelligent
man-machine interaction and diagnosis technology. The whole vehicle features
high safety, high reliability and high intelligence. The machine also
highlights strong power, low energy consumption, easy maintenance, and high
driving comfort.
Advantages
and highlights:
*
High Performance Engine
The
combination of strong power and outstanding vehicle performance provides higher
productivity with less cost.
*
Reliable Brake System
XDA40
adopts self oil cooled disc brakes system, ensure this Vehicle highly reliable
and long lifetime. Even in the muddy road, XDA40 also function as a highly
responsive.
The
large-capacity, continuously cooled, wet-multiple disc brakes also function as
a highly responsive retarder which gives the operator greater confidence at
higher speeds when travelling downhill.
*
Advance Driven System
Multifunction
transmission integrated with a variable torque converter having locking
function, integrated hydraulic retarder unit, advanced performance and
reliability. Gearbox shaft differential lock drive with higher ability. The
middle and rear drive shaft linked, real- time driving; wheel differential lock
to effectively deal with the bad road.
|
Item |
Unit |
Parameter |
||
|
Dimension |
Overall Length |
mm |
10690 |
|
|
Overall Width |
mm |
3370 |
||
|
Overall Height |
mm |
3793 |
||
|
Wheelbase front-mid |
mm |
4450 |
||
|
Wheelbase mid-rear |
mm |
1940 |
||
|
Tire center distance |
Front |
mm |
2600 |
|
|
Mid & Rear |
mm |
2600 |
||
|
Weight |
Total Weight |
kg |
73000 |
|
|
Payload |
kg |
39000 |
||
|
Curb Weight |
kg |
34000 |
||
|
Weight Distribution |
Unload |
Front |
kg |
17000 (50%) |
|
Mid & Rear |
kg |
17000 (50%) |
||
|
Loaded |
Front |
kg |
21600 (29.6 %) |
|
|
Mid & Rear |
kg |
51400 (70.4%) |
||
|
Power Train |
Engine |
/ |
Benz OM502 |
|
|
Rated Power |
kW/HP/rpm |
350/1800 |
||
|
Max Torque |
Nm/rpm |
2300/1300 |
||
|
Drive |
/ |
6×6 |
||
|
Tires |
/ |
29.5R25 |
||
|
Driving Performance |
Max speed |
km/h |
60 |
|
|
Min Turning Clearance |
mm |
8865 |
||
|
Max Grade ability |
% |
45 |
||
|
Max Steering Angle |
° |
±45 |
||
|
Minimum Ground Clearance |
mm |
565 |
||
|
Working Parameter |
Loading Height |
mm |
3180 |
|
|
Hoist Time |
s |
12 |
||
|
Hoist Angle |
° |
70 |
||
|
Service Capacities |
Fuel |
L |
550 |
|
|
Hydraulic Oil |
L |
300 |
||
|
Engine Oil |
L |
60 |
||
|
Cooling system |
L |
240 |
||
|
Axles-Wheel Gear Oil (Each) |
L |
11.5 |
||
|
Axles-differential (Each) |
L |
33 |
||
|
Body |
Struck |
m3 |
17.5/18.5 |
|
|
2:1Heaped |
m3 |
22.9/24 |
||
