XCMG new road reclaimers XLZ2305K China road cold recycler machine road maintenance equipment price



Summary
- Rated Power: 571kw
- Model Number:XLZ2305K
- Place of Origin: Jiangsu, China
- Rated Speed:12km/h
- Paving Width:2300mm
- Certification:CE/ISO
Specifications
- Weight:33500.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG new road reclaimers XLZ2305K China road cold recycler machine road maintenance equipment.
XLZ2305K road reclaimer is a set of multi-functional road maintenance equipment. It is mainly used for upgrading and reconstruction of old asphalt pavement. It is mainly used for mixing fillers, cement, limes and other objects with natural soil, so as to improve mechanical and physical properties of soil. It can be also used for milling damaged asphalt or asphalt concrete pavement with the thickness of 250mm and below.
1.The milling width of the road reclaimer is 2300mm; generally, the maximum milling depth is 430mm.
2.Running system has 4 speed governing gears. It has four wheels for running and steering; their low-pressure wide base big pattern tyres can run stably, with big adhesive force.
3.Sprinkling system has water spraying function; and it can manually and intelligently control the medium spraying volume.
4.Automatic depth control: built-in sensor of hydraulic cylinder is used for detection, and milling depth can be displayed on display.
5.The intelligent control system can achieve on-line display, fault diagnosis, fault alarm, maintenance hints and other advanced functions in working mode and walking mode; at the same time, various data can be directly read through display.
Item |
Unit |
XLZ2305K |
Milling width |
mm |
2300 |
Maximum milling depth |
mm |
430 |
Cutter spacing |
mm |
30×2 |
Diameter of milling wheel (with cutter) |
mm |
1480 |
Manufacturer |
|
Perkins |
Cooling type |
|
Water-cooling |
Model |
|
2806D-E18TTA |
The quantity of cylinder stator |
|
6 |
Rated power |
kW |
571 |
Engine speed |
rpm |
2100 |
Oil consumption: Full load |
kg/h |
119.3 |
Working speed |
km/h |
0-3 |
Traveling speed |
km/h |
0-12 |
Theoretical gradeability (working gear) |
% |
50 |
Ground clearance |
mm |
350 |
Front axle load |
195kg |
21000 |
Rear axle load |
kg |
14000 |
Shipping weight |
kg |
33500 |
Fuel tank |
L |
1500 |
Hydraulic oil tank |
L |
320 |
Water tank |
L |
200 |
Voltage of electric system |
V |
24 |
Machinery(length*width*height) |
mm |
9340x3218x3197 |
