XCMG Official Dumper Truck 65 Ton XGA5652DT New 6 Wheels Dumper Trucks For Sale

Chat Now 1 / EA (Min. Order)
Model: XGA5652DT
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official Dumper Truck 65 Ton XGA5652DT New 6 Wheels Dumper Trucks For Sale

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

Specifications

  • Weight:26500.000kg
  • Condition:New
  • Moving Type:Wheel

XCMG Official Dumper Truck 65 Ton XGA5652DT New 6 Wheels Dumper Trucks For Sale

XCMG Official Dumper Truck 65 Ton XGA5652DT New 6 Wheels Dumper Trucks.



* According to each of the engine torque characteristic curve, perfectly match the different types of Fast manual gearbox, Allision automatic gearbox, to protect the most energy rationalization output, the vehicle has an excellent starting ability, climbing ability.



* Optimized arrangement of the traditional system architecture, reducing the loss of energy transfer process to ensure the kinetic energy efficient, rapid transmission.



* Using the unique steering and steering follower, the steering mechanism. Steering light, the failure rate lower.



* Dual-circuit brake system equipped with high pressure geography accumulator volume increases, the brake pressure increasing 25% to 1 Mpa, shorten braking distance.

XCMG Official Dumper Truck 65 Ton XGA5652DT New 6 Wheels Dumper Trucks For Sale



Vehicle model

XGA5652DT

Mass parameter

Curb weight

26500kg

GVW

65000kg

Performance

Max. speed

40km/h

Min. turning diameter

9.4m

Grade ability

46%

Fuel tank

400L

Dimensions

Overall dimensions

Length

8860mm

Width

3275mm

Height

3740mm

Wheelbase

3800+1560mm

Wheel track

Front tire

2505mm

Rear tire

2250mm

Min.Clearance

380mm

Approach angle

30°

Departure angle

48°

Front overhang

1685mm

Rear overhang

1815mm

Cargo Size

5800×3000×1600mm

Cab

Model

K20 HanWo P6

Members Allowed

1

Engine

Model

WD12G420E211

Displacement

11.596L

Output power

309kW

Max. torque speed

1750N·m

Clutch

Model

Φ430

Pull type diaphragm spring clutch

Operation

Hydraulic manual

Transmission

Model

Allison 4500 ORS

PTO

QH70

Operation

Flexible shaft

Forward ratio

12.44/8.31/6.09/4.54/3.36/2.47/1.81/1.35/1.00

Reverse ratio

12.99

Driven axle

Model

25T PENGXIANG

Main reducer ratio

11.125/13.51

Brake type

Drum

Differential lock

Inter-axle differential lock

Front axle

Model

13T PENGXIANG

Brake type

Drum

Wheel

Rim

10.00W-24

Tire

14.00-24NHS

Frame

Model

Box beam

HxW-t

450mm

Frame Width

1000mm

Suspension

Front

Type

Leaf spring

Leaf springs

14

Rear

Type

Balanced suspension

Leaf springs

13

Steering

Model

Φ120/Circulating ball type hydraulic power

Steering Ration

23.27

Max. pressure of pump

17MPa

Brake System

Rated pressure

1MPa

Service brake system

Dual circuit pneumatic braking

Parking brake system

Spring energy storage air brake

Auxiliary braking system

Engine exhaust brake+Retarder

Electrical system

Voltage

24V

Generator power

2.2kw

Battery voltage/capacitance

2×12 V/165Ah
