- Brand Name:XCMG
- Place of Origin:China
- Product Name:G5BF255398D4CB
- Display online time:2020-11-07
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:3 Months
- Moving Type:other
- Outline dimension:14550×2530×4000mm
- Emission standard:China VI
- Placing height:57.5m
- Theoretical output:170M3/h
- Pumping pressure:8.6Mpa
- Transfer tube:Rock valve
1.Bright spot of product:
NO.1Ultimately safe boom
The design idea of high reliability, boom full-working condition simulation calculation and testing, and German manufacturing technology ensure safer structure of the boom;
High precision electro-hydraulic proportional intelligent control technology realizes more precise micro-control.
NO.2Lower structure of high rigidity
One-level arc-shaped telescoping outrigger structure achieves higher rigidity of lower structure and better working stability of overall unit;
Ultimately simple telescoping device has less fault points, with higher operation reliability.
NO.3 Hydraulic system of outstanding performance
Fully-hydraulic switchover hydraulic system adopts MPS switchover buffering technology, featuring ultra-low pressure loss, small switchover impact and low oil consumption.
NO.4 Intelligent control system
Optimized control strategy of overall unit operates the equipment to an extreme level;
Digital design idea realizes digitization control of facility’s running status;
Fault diagnosis module + “black box” function can not only monitor the running state in real time, but also playback the history running status.
NO.5Efficient pumping system of rock valve
Exclusive-patent rock valve pumping system and optimized pipeline layout achieve high pumping efficiency and long service life, more economical;
Large flow hydraulic pump + “smart pipe clearing” mode achieves better concrete adaptability.
NO.6Easy-wear parts with super-long service life
Reinforced rock valve, one-piece alloy cutting ring and highly wear-resisting double-layer pumping pipe prolong the service life of easy-wear parts.
NO.7Unique and ingenious details
Friendly human-computer interaction, open-type layout of overall unit, design idea of less maintenance times and five-protection design of overall unit show the unique details and the ultimately high quality.
|Emission standard||China VI|
|Transfer tube||Rock valve|
