XCMG 32m fire truck YT32M1 turntable ladder ladder price, MACHMALL

Special Vehicle > Fire & Rescue Vehicle > Aerial Ladder Fire Truck

XCMG 32m fire truck YT32M1 turntable ladder ladder price

View All >

Model： YT32M1

Engine： benz

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG 32m fire truck YT32M1 turntable ladder ladder price

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

YT32M1

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Model Number

Brand Name

Place of Origin

Size

Max Work Height

Fuel Type

Emission Standard

Tank Capacity

Horsepower

Transmission Type

Type

Drive Wheel

Certification

Special Vehicle

YT32M1

XCMG

Xuzhou,Jiangsu,China

11380*2500*3880mm

32m

Diesel

EURO 5

Water 3000kg + foam 1900kg

351 - 450hp

Manual

Aerial Ladder

6x4

CE/ISO9001

+ Add a Product

Summary

Model Number:YT32M1
Brand Name:XCMG
Place of Origin:Xuzhou,Jiangsu,China
Size:11380*2500*3880mm
Max Work Height:32m
Fuel Type:Diesel
Emission Standard:EURO 5
Tank Capacity:Water 3000kg + foam 1900kg
Horsepower:351 - 450hp
Transmission Type:Manual
Type:Aerial Ladder
Drive Wheel:6x4
Certification:CE/ISO9001

Specifications

weight:28150.000kg
Condition:New
Moving Type:Other
Engine rated/max power:325kW/320kW/1800rpm

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG 32m fire truck YT32M1 turntable ladder ladder price

XCMG 32m fire truck YT32M1 turntable ladder ladder.

YT32M1 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security

It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.

Advantages and highlights:

1. YT32M1 chassis adopts Benz chassis with advanced performance and large loading capacity, with sufficient margin of power.

2. The firefighting system is equipped with full functions and the pump gun has excellent performance. The inlet and outlet and control valves are well equipped and easy to operate.

3. Various working condition curves control mode can efficiently improves rescuing capability of the fire truck and bring the functions of fire truck into full play.

4. Independent working platform has quick disassembly and reassembly function so as to realize various working conditions.

XCMG 32m fire truck YT32M1 turntable ladder ladder price

Outline dimension (L×W×H)	11450×2500×3810mm
Max. total mass	29000kg
Max. travel speed	≥90km/h
Min. turning diameter	≤23m
Approach angle	≥16°
Departure angle	≥12°
Max. grade ability	≥25%
Outrigger span	Longitudinal span	5400mm
	Lateral span	5200mm
Load capacity of working platform	300kg
Max. working height	32m
Maximum working range	22m
Boom elevating range	Telescopic boom -12°~+75°
Slewing range	360° full-rotation
Outrigger unfolding time	≤25s
Time for boom raising to rated height and rotating 90°	≤55s
Max. slewing speed of turntable	0.5~1.5r/min
Fire pump	Rated flow	50 L/s
	Rated pressure	1.5 MPa
Fire monitor	Model	Zhangqiu PLKD48
	Rated flow	48 L/s
	Rated pressure	≤1.0MPa
	Reach	≥60m(water)
		≥55m(foam)

XCMG 32m fire truck YT32M1 turntable ladder ladder price

uMore foam fire truck

XCMG 32m fire truck YT32M1 turntable ladder ladder price
