XCMG factory 100HP road graders GR100 for sale
FOB for Road Mach Reference Price:Get Latest Price
$40000.00-$45000.00 1 / EA (Min. Order)
Model: GR100
Engine: Cummins
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG factory 100HP road graders GR100 for sale
XCMG factory 100HP road graders GR100 for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:7000.000kg
  • Condition:New
  • Moving Type:Other
  • Dimension(L*W*H):6880*2375*3150mm
  • Weight:7000kg
  • Rated power/speed:75/2400kw/rpm
  • Ground clearance (front axle):550mm
  • Working system pressure:16MPa
  • Forward Speed:38km/h
  • Reverse Speed:24km/h

XCMG factory 100HP road graders GR100 for sale

XCMG factory 100HP road graders GR100.



XCMG GR Series Road Graders:

XCMG GR series road graders cover a wide range of models, including small type,conventional type,mining type,type for cold zone, desert and plateau as well as CE certified series. Models are of GR100,GR180,GR215,GR5505, etc.



Working Scope of XCMG Road Grader GR100:

GR100 road grader are mainly used for large-area ground leveling, trenching, scraping, bulldozing, and soil loosening operations on highways, airports, and farmland. It is a necessary engineering machinery for national defense engineering, mine construction and other building construction, water conservancy construction, and farmland improvement.



Highlight of XCMG Road Grader GR100:

1. Adopting an articulated frame, it is of small turning radius and flexible mobility with front-wheel steering.

2. The electro-hydraulic control power shift gearbox has 6 forward gears and 3 reverse gears.

3. It adopts supporting hydraulic parts and works reliably.

4. The rear axle is a three-section drive axle equipped with a self-locking differential.



XCMG GR100 Road Grader Optional Configuration:

Front bulldozing board, rear ripper, front ripper, automatic leveling device



Market Share of XCMG Road Grader:

XCMG GR series road graders are leading the industry, and their Chinese market share and export volume have been ranked first in the industry for four consecutive years.

 XCMG factory 100HP road graders GR100 for sale

Item

GR100

Engine model

J-XZGR100-4BT3.9

Rated power/speed

75(2400r/min)

Overall dimension (standard)

6880X2375X3150

Total weight (standard)

7000kg

Tire specification

16/70-24

Ground clearance (front axle)

550mm

Tread

1900mm

Space of front and rear axles

4885 mm

Forward velocity

5,8,11,17,24,38km/h

Reverse speed

5,11,24km/h

Tractive effort f=0.75

39.2N

Maximum gradeability

20%

Tire inflation pressure

300kPa

Working system pressure

16MPa
