Specs & Compare

Details

Specifications

Weight:16100.000kg
Condition:New
Moving Type:Other
Applicable Industries:Farms, Construction works
Forward Speed(km/h):38
Place of Origin:China
Dimension(L*W*H):9180*2625*3470mm
UNIQUE SELLING POINT:Environmental,Energy-saving,Large power engine
Rated power/speed:160kW/2200rpm
Reverse Speed(km/h):23
Brand Name:XCMG
Certification:CE/ISO
Engine Brand:Cummins
Engine Model:6CTA8.3-C215

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG Official 180hp motor graders GR180 grader motor for sale

XCMG Official 180hp motor grader machine GR180.

The motor grader is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. It is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.

Advantages and Highlights:

1. Dongfeng Cummins Engine, ZF Technology Gearbox, and XCMG Drive Axle make the drive system power matching more reasonable and reliable.

2. Double-circuit hydraulic brake system makes the brake more reliable and stable.

3. Steering to the load sensing system, the main hydraulic components adopt international support to ensure the stability and reliability of the system.

4. Use XCMG special enhanced work devices.

5. The blade body adopts adjustable large chute and double slide mechanism, and the working blade adopts high-strength and wear-resistant material.

6.Various options expand the machine's performance and working range.

XCMG Official 180hp motor graders GR180 grader motor for sale

Item			GR180
Basic parameters	Engine model		6CTA8.3-C190-Ⅱ
	Rated power/speed		142kW/2200rpm
	Overall dimension (standard)		8900x2625x3420
	Total weight (standard)		15400 kg
	Tire specification		17.5-25
	Ground clearance (front axle)		430mm
	Tread		2156mm
	Space of front and rear axles		6219 mm
	Space of middle and rear wheels		1538 mm
Performance parameters	Forward velocity		5､8､11､19､23､38km/h
	Reverse speed		5､11､23km/h
	Tractive effort f=0.75		≥79 kN
	Maximum gradeability		≥25%
	Tire inflation pressure		260kPa
	Working system pressure		18MPa
	Transmission pressure		1.3—1.8Mpa
Working parameters	Maximum steering angle of front wheel		±50°
	Maximum slant angle of front wheel		±17°
	Maximum oscillating angle of front axle		±15°
	Maximum oscillating angle of equilibrium box		±15°
	Maximum steering angle of frame		±27°
	Minimum turning radius		7.3m
	Scrape knife	Maximum lift height	450mm
		Maximum cutting depth	500mm
		Maximum tilt angle	90°
		Cutting angle	28°—70°
		Angle of revolution	360°
		Length & chord height	3965x610mm
Oil filling amount	Coolant		50L
	Fuel tank		280L
	Engine		24L
	Transmission		38L
	Balancing box		46L
	Drive axle		28L
